Case IH 2294 Tractor Workshop Service Repair Manual

Case IH 2294 Tractor Workshop Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 61730
Brand
CASE
Equipment
Tractors
Models covered
2294, Case
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Case IH
Model:
2294
Model Variant:
2294 (standard)
Production Years:
1985-1989 (approx.)
👋 Introduction
Overview
Target Audience:
Owners, technicians, and mechanics servicing Case IH 2294 tractors
Market Position:
Utility tractor for farming and agricultural operations
Key Features:
Durable design, reliable diesel engine, 8-speed transmission, dual-stage clutch
Competitive Analysis
Advantage:
Comprehensive service information covering maintenance, repair, and troubleshooting
Advantage:
High-quality diagrams and procedures for accurate repairs
📋 Manual Details
Specifications
Coverage Areas:
Complete tear-down, repair, and re-assembly instructions
Page Count:
Over 1000 pages of detailed instructions
Manual Type:
Full Service Repair Manual
Language:
English
Format:
PDF
Delivery Method:
Instant Download
📖 Manual Coverage
Systems Covered
Engine:
Detailed procedures for engine disassembly, inspection, and overhaul
Cooling System:
Radiator, thermostat, water pump service
Fuel System:
Injection pump, injectors, fuel lines, and filters
Electrical System:
Wiring diagrams, starter, alternator, and battery
Power Train:
Transmission, clutch, differential, final drives
Steering and Brakes:
Steering gear, hydraulic brakes, and linkage
Hydraulics:
Pump, valves, cylinders, and 3-point hitch
Cab and Sheet Metal:
Body panels, cab components, and interior
Procedures Included
Maintenance Schedules:
Recommended service intervals and checks
Lubrication:
Oil and grease points
Disassembly and Assembly:
Step-by-step instructions for each component
Inspection:
Procedures for measuring wear and clearances
Diagnosis and Troubleshooting:
Charts and testing procedures
Adjustment:
Specifications for correct setting
Repair:
Detailed overhaul procedures
Technical Depth
Comprehensive:
Covers all systems in detail
Diagrams:
Electric and hydraulic schematics
Specifications:
Torque values and clearances
Parts Information
Part Numbers:
Reference numbers for ordering
Exploded Views:
Illustrations showing parts breakdown
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Any device with PDF reader (PC, Mac, tablet, smartphone)
Requirements:
PDF reader software, e.g., Adobe Acrobat
Searchability:
Searchable text, bookmarks included
Print Quality:
High-resolution pages for clear printing
Binding Type:
Digital (no physical binding)
Paper Type:
N/A - digital file
⚙️ Engine Specifications
Engine Options
Engine Model:
Case IH 6-590 (approx.)
Type:
6-cylinder diesel
Displacement:
5.9 liters (approx., 359 ci)
Bore and Stroke:
4.0 in x 4.75 in (approx.)
Compression Ratio:
16.5:1 (approx.)
Performance
Rated Power:
135 HP (approx.)
Rated RPM:
2400 RPM (approx.)
Torque:
High torque rise for lugging ability (approx.)
Fuel System
Type:
Direct injection
Injection Pump:
Bosch or similar (approx.)
Fuel Capacity:
70 gallons (approx.)
🔧 Transmission
Standard Transmission
Type:
8-speed manual
Gear Configuration:
8 forward, 2 reverse (approx.)
Clutch:
Dual-stage clutch
Optional Transmission
Type:
N/A - not specified for this model
Features
Shifting:
Fully synchronized
Speeds:
Up to 25 km/h (approx.)
📐 Dimensions
Exterior
Wheelbase:
120 inches (approx.)
Length:
176 inches (approx.)
Width:
96 inches (approx.)
Height:
117 inches (approx.)
Weights
Curb Weight:
11,500 lbs (approx.)
Ballast Weight:
Varies depending on configuration
🛡️ Safety Features
Ratings
Crash Test Information:
N/A - not applicable for agricultural tractors
Active Features
Brakes:
Hydraulic wet disc brakes
Steering:
Hydrostatic power steering
Passive Features
Roll Over Protection:
ROPS cab (optional or standard on some models)
Seat Belt:
Standard
💡 Technology Features
Infotainment
Audio System:
N/A - typical for era, was simple radio or no audio
Driver Assistance
Monitoring:
Warning lights for engine and systems (approx.)
Guidance:
None (modern GPS not available)
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 100 hours (approx.)
Hydraulic Fluid Check:
Every 10 hours (approx.)
Oil Filter Change:
Every 200 hours (approx.)
Air Filter Service:
Clean daily, replace as needed
Transmission Fluid Change:
Every 1000 hours (approx.)
Coolant Change:
Every 2 years or 1500 hours (approx.)
Fluid Specifications
Engine Oil:
API CC/CD grade 15W-40 (approx.)
Hydraulic Fluid:
Hy-Tran Ultra or equivalent (approx.)
Transmission Fluid:
Hy-Tran Ultra or equivalent (approx.)
Coolant:
Ethylene glycol with corrosion inhibitors
Known Issues / Common Wear Items
Common Issue:
Injector pump wear over time
Common Wear:
Clutch disc worn
Common Wear:
Hydraulic seals leaking
📚 Vehicle History
Brand Heritage
Manufacturer:
Case IH (International Harvester merger)
Heritage:
Long history in agricultural equipment since 1842
Model Evolution
Predecessor:
Case 2290 (approx.)
Successor:
Case IH 5240 (approx.)
Production Location
Plant:
Hinsdale, Illinois, USA (approx.)
🏆 Awards & Recognition
Recognitions
Industry Recognition:
Not widely documented - no specific awards found

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
