Case CX75SR Crawler Excavator Workshop Repair Service Manual

Case CX75SR Crawler Excavator Workshop Repair Service Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 62975
Brand
N/A
Equipment
Tractors
Models covered
C, Case
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Case
Model:
CX75SR
Model Variant:
Crawler Excavator
Production Years:
2009-2012 (approx.)
VIN / Serial Number Location:
Refer to manual for exact locations
👋 Introduction
Market Position
Target Audience:
Compact utility class excavator for construction, landscaping, and utilities
Positioning:
Reliable and versatile compact excavator in the 7-tonne class
Key Features
Advantage:
Powerful performance with short tail swing for confined spaces
Key Feature 1:
Auto idle and deceleration system for fuel efficiency
Key Feature 2:
Comfortable operator cab with low noise levels
📋 Manual Details
Coverage
Models Covered:
Case CX75SR crawler excavator
Production Years:
2009-2012 (approx.)
Manual Specifications
Manual Type:
Workshop Repair Service Manual
Language:
English
Format:
PDF (digital download)
Delivery Method:
Instant digital download
Page Count:
Over 500 pages (approx.)
📖 Manual Coverage
Systems Covered
Engine:
Complete engine removal, disassembly, inspection, and repair
Fuel System:
Fuel tank, lines, injection pump, injectors
Cooling System:
Radiator, water pump, thermostat
Electrical System:
Wiring diagrams, starter, alternator, sensors, ECU
Hydraulic System:
Pumps, valves, cylinders, hoses, hydraulic schematic
Transmission:
Travel and swing drives, gearboxes
Undercarriage:
Track, idlers, sprockets, rollers
Swing System:
Swing motor, swing bearing, swing reduction
Bucket and Attachments:
Quick coupler, bucket linkage, pins and bushings
Control System:
Joystick controls, pilot system, electronic control
Operator Cab:
Air conditioning, heater, gauges, controls
Frame and Body:
Main frame, counterweight, track frame
Cleaning and Inspection:
Standard cleaning and inspection procedures
Troubleshooting:
Diagnostic fault codes and troubleshooting guides
Procedures Included
Service Procedures:
Periodic maintenance, lubrication, adjustments
Repair Procedures:
Step-by-step disassembly, repair, and reassembly with torque specs
Technical Depth:
Comprehensive, intended for experienced technicians and DIYers
Special Tools:
List of required special tools and usage
Parts Information
Parts Manual Reference:
Refer to separate parts manual for part numbers
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Compatible with all modern devices that support PDF
Requirements:
PDF reader software required
Searchability:
Fully searchable and printable
Physical Media
Print Quality:
High-resolution text and diagrams
Binding Type:
Digital (electronic download)
Paper Type:
N/A - digital format
⚙️ Engine Specifications
Engine Details
Engine Make:
Case (likely supplied by Iveco or similar)
Engine Model:
N/A - not specified for this model
Engine Type:
Diesel, four-cycle, turbocharged (available)
Displacement:
N/A - not specified for this model
Power Output:
Approximately 54 hp (40 kW)
Torque:
N/A - not specified for this model
Fuel System:
Direct injection with electronic control
Cooling:
Liquid-cooled
🔧 Transmission
Powertrain
Standard Transmission:
Hydrostatic drive for travel
Optional Transmission:
None - standard hydrostatic
Travel Speed:
Low and high range, up to 3.5 mph (5.6 km/h)
Features:
Two-speed travel, automatic downshift
📐 Dimensions
Exterior
Overall Length:
Approximately 6.5 meters (21.3 ft)
Overall Width:
Approximately 2.2 meters (7.2 ft)
Overall Height (to top of cab):
Approximately 2.5 meters (8.2 ft)
Weights
Operating Weight:
Approximately 7700 kg (16,975 lbs)
🛡️ Safety Features
Ratings
Crash Test Information:
N/A - off-highway equipment
Active and Passive
Active Safety:
ROPS/FOPS certified cab, seatbelt, backup alarm, mirrors
Passive Safety:
Emergency stop, hydraulic safety lock, reinforced cab structure
💡 Technology Features
Infotainment
Audio System:
AM/FM radio with speakers (optional)
Display:
LCD instrument cluster with gauges
Operator Assistance
Auto Idle:
Engine auto-idle to save fuel
Power Boost:
One-touch power boost for increased digging force
Travel Mode:
Selectable travel speed modes
🔧 Maintenance
Service Intervals
Oil and Filter Change:
Every 250 hours or 6 months
Fuel Filter Replacement:
Every 500 hours
Hydraulic Oil Change:
Every 2000 hours or 2 years
Track Tension Adjustment:
Every 100 hours
Fluid Specifications
Engine Oil:
API CH-4 or higher, SAE 15W-40 (typical)
Hydraulic Oil:
ISO VG 46 or equivalent
Coolant:
Ethylene glycol based, long-life
Common Wear Items
Known Issues:
Leaking cylinder seals, track wear, electrical connection corrosion
Common Replacement Parts:
Track pads, pins and bushings, filters, hoses
📚 Vehicle History
Manufacturer Background
Brand Heritage:
Case Construction Equipment, a leading global manufacturer
Model Evolution:
CX75SR is part of the CX series compact excavators introduced in the late 2000s
Production Location:
Manufactured in various Case plants (e.g., Brazil or Europe)
🏆 Awards & Recognition
Acknowledgments
Model Recognition:
No specific awards are documented for this model
Era Recognition:
Case excavators have been recognized for innovation and reliability

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
