PIPER CHEROKEE Service Manual PA-28-140 150 160 180 235 200 - Download PDF

PIPER CHEROKEE SERVICE MANUAL PA-28-140/150/160/180/235/200 PART 753-586 CHEROKEE SERVICE MANUAL CARD 1 OF 4 PA-28-140 PA-28-150 PA-28-160 PA-28-180 PA-28-235 PA-28R-180 PA-28R-200 * INSTANT DOWNLOAD - NO WAITING * LANGUAGE: English * FORMAT: PDF * COMPATIBLE: Win/ Mac * PAGES: 916 * SEARCHABLE - BOOKMARKED - INDEXED When servicing or inspecting vendor equipment installed in Piper aircraft, it is the user's responsibility to refer to the applicable vendor publication. 1-1. GENERAL. This manual contains service and maintenance instructions for PA-28-140.-150. -160. -180. -235 and PA-28R-180 200 Cherokees. designed and manufactured asversatile airplanes in the personal and business aviation field. by the Piper Aircraft Corporation . Vero Beach. Florida. 1-2. SCOPE OF MANUAL. Sections II and III comprise the service part of this manual, whereas Sections IV through XIII comprise the maintenance instructions. The service instructions include ground handling, servicing and inspections. The maintenance instructions for each system include troubleshooting, removal and installation of components, and corrective maintenance and testing; each major system of the airplane is covered in a separate section. Only qualified personnel should perform the operations described in this manual. The description of the airplane included in this section is limited to general information. Section II gives leading particulars and principal dimensions, while each major system is described in its appropriate section of the manual. For a more detailed description of the airplane, refer to the Owner's Handbook, or Pilot's Information Manual for the particular airplane. 1-3. DESCRIPTION. The Cherokee PA-28 is a single-engine. low-wing monoplane of all metal construction. The standard PA-28-140 is a two place. with third and fourth family seats available as optional equipment. The PA-28-150. -160. -180. -235 and PA-28R-180 200 are four place airplanes. Paragraphs 1-4 through 1-17 provide descriptions of the major components and systems. 1-4. WING. The laminar flow wing is of all-metal stressed-skin, full cantilever, low-wing design, consisting of two wing panels bolted to a spar box assembly in the fuselage. The wing tips are removable. The ailerons are cable and push rod controlled and are dynamically balanced. The trailing edge wing flaps are manually operated. 1-5. EMPENNAGE. The empennage consists of the fin, rudder, stabilator and stabilator trim tabs. The stabilator is dynamically balanced. _____________________________ Fully Bookmarked chapters for easy navigation allowing you to identify the exact service repair procedures in the quickest time possible. Detailed illustrations, exploded diagrams, drawings and photos guide you through every service repair procedure. Completely Indexed, Bookmarked and Searchable! Lots of pictures, diagrams/illustrations, and charts * JUST CLICK THE GREEN & WHITE - DOWNLOAD NOW BUTTON - at the Top Right-Hand Side of this Page & get this Manual - IMMEDIATELY * We have Thousands of Manuals - email us about any you might need.
