Kubota L2350DT Tractor Illustrated Master Parts List Manual

Kubota L2350DT Tractor Illustrated Master Parts List Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 24233
Brand
Kubota
Equipment
Tractors
Models covered
275, Case
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Kubota
Model:
L2350DT
Model Variant:
DT (4-wheel drive)
Production Years:
1985-1994 (approx.)
👋 Introduction
Market Position
Target Audience:
Technicians, DIY owners, and agricultural machinery enthusiasts
Market Position:
Compact utility tractor segment, known for reliability and versatility
Competitive Analysis
Advantage:
High durability, ease of maintenance, and strong dealer support compared to competitors of the era
Key Features
Key Features:
4-wheel drive, live PTO, power steering, and a robust 3-point hitch
📋 Manual Details
Coverage Areas
Coverage:
Complete parts listing for all major assemblies and components
Page Count:
Approximately 300-400 pages (exact count not specified)
Manual Type and Language
Manual Type:
Illustrated Master Parts List
Language:
English
Format:
PDF (digital download)
Delivery
Delivery Method:
Instant download after purchase
📖 Manual Coverage
Systems Covered
Engine:
Complete engine parts with part numbers and exploded diagrams
Transmission:
Gearbox, clutch, and drive components
Hydraulics:
Pumps, valves, and hydraulic cylinders
Electrical:
Wiring harness, switches, and lighting components
Steering:
Power steering system components
Brakes:
Service and parking brake parts
PTO (Power Take-Off):
PTO shaft and related components
3-Point Hitch:
Lift arms, links, and hydraulic control parts
Front Axle:
4WD front drive components
Rear Axle:
Differential and final drive parts
Procedures Included
Assembly:
Component assembly and disassembly guidance
Part Number Identification:
Each part numbered with OEM part numbers
Technical Depth
Illustrations:
Detailed exploded views for each assembly
Compatibility:
Covers standard, optional, and replacement parts
Parts Information
Part Numbers:
OEM Kubota part numbers for each item
Quantity Required:
Field indicating the number needed per assembly
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Works on any PDF reader (Adobe, Preview, etc.)
Searchability:
Text searchable for quick part location
Print Quality
Resolution:
High-resolution scans for clear readability
Printing:
Suitable for printing on standard letter or A4 paper
Binding and Paper
Binding Type:
Digital - no physical binding
Paper Type:
N/A - digital file only
⚙️ Engine Specifications
Primary Engine
Model:
Kubota D1402 (diesel, naturally aspirated)
Displacement:
1.4 L (1388 cc)
Power Output:
Approximately 23-25 hp (17-18.6 kW)
Fuel System:
Indirect injection, mechanical fuel pump
Engine Options
Variants:
No significant engine options; standard D1402
🔧 Transmission
Standard Transmission
Type:
Manual, gear drive
Speeds:
8 forward and 2 reverse (8F/2R)
Clutch:
Dry single plate
Optional Transmission
Option:
None - only standard gear transmission
Features
Live PTO:
Live independent PTO (540 rpm)
4WD:
Four-wheel drive with mechanical engagement
📐 Dimensions
Exterior
Wheelbase:
Approximately 1660 mm (65.4 in)
Length:
Approximately 2950 mm (116.1 in)
Weights
Curb Weight:
Approximately 1370 kg (3020 lb)
🛡️ Safety Features
Ratings / Crash Test Information
Crash Test Rating:
N/A - not applicable for tractors
Active Features
Brakes:
Wet disc brakes for reliable stopping
Passive Features
Rollover Protection:
Optional ROPS (Roll-Over Protective Structure)
💡 Technology Features
Infotainment
Audio System:
N/A - not equipped from factory
Driver Assistance
Instrumentation:
Basic gauges for temperature, oil pressure, and fuel
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 100 hours or annually
Transmission Oil Change:
Every 400 hours
Hydraulic Oil Change:
Every 400 hours
Fluid Specifications
Engine Oil:
API service classification CC or CD, SAE 10W-30 or 20W-40
Transmission/Hydraulic Fluid:
Use Kubota UDT fluid or equivalent
Known Issues / Common Wear Items
Common Issue:
Injector failure due to fuel contamination
Common Wear Item:
Clutch disc - check for wear at regular intervals
Common Wear Item:
Tires - replace when tread depth is low
📚 Vehicle History
Brand Heritage
Manufacturer:
Kubota Corporation
Country of Origin:
Japan
Model Evolution
Predecessor:
L2350 (2WD) / L2250 series
Successor:
L2450 / L2650 series
Production Location
Production Plants:
Sakai and Tsukuba plants in Japan
🏆 Awards & Recognition
Recognitions
Industry Awards:
No specific awards documented for this model

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
