Kubota B21 Tractor Illustrated Master Parts List Manual

Kubota B21 Tractor Illustrated Master Parts List Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 24148
Brand
Kubota
Equipment
Lawnmowers
Models covered
Other Wheel Horse Manuals, Wheel Horse
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Kubota
Model:
B21
Model Variant:
Tractor (compact utility)
Production Years:
1993-2005 (approx.)
👋 Introduction
Market Position
Target Audience:
Landowners, small farmers, contractors, and equipment technicians needing a reliable compact tractor for loader and backhoe work.
Competitive Advantage
Key Advantage:
The B21 is a dedicated TLB (tractor-loader-backhoe) model, distinguishing it from standard compact tractors by offering an integrated, heavy-duty backhoe and a robust front loader, with high ground clearance and a rigid frame.
Key Features
Engine:
Kubota 4-cylinder diesel, 4WD standard.
Hydraulics:
Open center with multiple control valves for loader, backhoe, and 3-point hitch.
Transmission:
GST (Glide Shift Transmission) provides clutchless shifting between ranges.
PTO:
Independent rear PTO (540 rpm).
3-Point Hitch:
Category I with position control and telescopic lower links.
📋 Manual Details
Manual Information
Coverage Areas:
Complete parts breakdown for all major assemblies: engine, clutch, transmission, front axle, rear axle, brakes, steering, hydraulic system, electrical system, loader, backhoe, and optional equipment.
Page Count:
Approximately 500 pages (illustrated parts manual).
Manual Type:
Illustrated Master Parts List Manual.
Language:
English
File Format:
PDF
Delivery Method:
Instant download
📖 Manual Coverage
Systems Covered
Engine and related parts:
Complete engine components: block, head, pistons, crankshaft, oil pump, fuel injection pump, injectors, filters, and more.
Clutch:
Clutch disc, pressure plate, release bearing, and linkage.
Transmission:
Gear components, shift forks, shafts, synchronizers (if applicable), bearings, seals, and the GST assembly.
Front axle and steering:
Front differential, final drives, axle shafts, kingpins, steering gear, tie rods, and front wheel components.
Rear axle and final drives:
Rear differential, ring gear and pinion, axle housings, sun gears, planet gears, and wheel flanges.
Brakes:
Disc brakes, master cylinder, brake lines, and parking brake components.
Hydraulic system:
Hydraulic pump, control valves for 3-point hitch, steering, loader, and backhoe; cylinders, hoses, seals, and filters.
3-point hitch:
Lift arms, lower links, top link, and associated pins and hardware.
PTO system:
Independent PTO clutch, shaft, and drive gears.
Electrical system:
Starter, alternator, regulator, wiring harness, switches, lights, and battery.
Loader and backhoe:
Full parts breakout for the Kubota B21 loader and backhoe, including boom arms, cylinders, valve bodies, bucket, and pins.
Body and chassis:
Frame, sheet metal, fenders, grille, ROPS canopy assembly, and seat.
Cooling system:
Radiator, cooling fan, thermostat, hoses, and water pump.
Fuel system:
Fuel tank, lines, filters, and injection components.
Exhaust system:
Exhaust manifold, muffler, and piping.
Procedures Included
Parts identification:
Every part has a reference number and description for easy ordering.
Illustrations:
Detailed exploded-view drawings to aid in disassembly and assembly.
Technical depth:
Intended for technicians and owners who require accurate component-level identification; does not include service procedures.
Parts Information
OEM part numbers:
Original Kubota part numbers are listed for each component.
Quantity per assembly:
Includes required number of parts per assembly unit.
📊 Manual Specifications
Digital Format
File Format:
PDF
Compatibility:
Windows, macOS, Linux, iOS, Android – any PDF reader.
Requirements:
A web browser for download and a PDF reader for viewing.
Searchability:
Bookmarked sections and searchable text for fast lookups.
Print Quality (if printed)
Print Quality:
High-resolution 300 DPI for clear part illustrations.
Binding Type:
Digital (not physically bound)
Paper Type:
N/A – digital file only; if printed, use standard paper.
⚙️ Engine Specifications
Primary Engine
Engine Model:
Kubota D1403-B
Type:
4-cylinder, liquid-cooled, indirect injection diesel.
Displacement:
1.4 L (85.5 cu in).
Gross Power:
21.0 horsepower (15.7 kW) at 3000 rpm (SAE).
PTO Power:
17.4 horsepower (13.0 kW) at rated rpm.
Fuel System:
Indirect injection with glow plug starting.
Fuel Type:
Diesel.
🔧 Transmission
Standard Configuration
Standard Transmission:
Kubota GST (Glide Shift Transmission) with 8 forward and 4 reverse gears.
Features
Clutchless shifting:
Shifting between speeds within ranges without using the clutch pedal.
Four-wheel drive:
Integral 4WD with front axle drive.
Differential lock:
Rear differential lock for improved traction.
📐 Dimensions
Measurements
Wheelbase:
1,530 mm (60.2 in)
Overall Length (with loader and backhoe):
3,230 mm (127.2 in)
Overall Width:
1,280 mm (50.4 in)
Overall Height (ROPS):
2,180 mm (85.8 in)
Curb Weight:
1,190 kg (2,624 lb) – approximate, includes loader and backhoe.
🛡️ Safety Features
Safety Overview
Ratings / Crash Test:
N/A – off-road tractor not subject to vehicle crash tests.
Active Safety:
Four-wheel drive for better traction; independent braking; differential lock.
Passive Safety:
ROPS canopy is standard; seat belt is required for rollover protection. No airbags.
💡 Technology Features
Infotainment and Assistance
Infotainment:
N/A – tractor has no audio system.
Driver Assistance:
GST transmission and hydrostatic power steering.
🔧 Maintenance
Service Intervals
Engine oil change:
Every 50 hours or annually, whichever comes first.
Hydraulic oil change:
Every 500 hours or every 2 years.
Coolant change:
Every 2 years.
Fluid Specifications
Engine oil:
API CF or higher, SAE 15W-40 or 10W-30 depending on ambient temperature.
Transmission / hydraulic oil:
Kubota UDT fluid or equivalent such as SAE 20/30.
Coolant:
Ethylene glycol-based antifreeze with SCA (supplemental coolant additive) recommended.
Common Issues
Known wear items:
Loader and backhoe pivot pins, hydraulic cylinder seals, and glow plugs.
Notice:
Parts manual aids in identifying the correct replacement parts; refer to owner's manual for specific maintenance procedures.
📚 Vehicle History
Heritage
Brand Heritage:
Kubota Corporation, founded in 1890 in Japan; known for compact diesel engines and tractors since 1960s.
Model Evolution
Evolution:
The B21 (1993–2005) was a member of compact tractor line, designed specifically as a TLB. It was succeeded by the B26 in the mid-2000s with enhancements.
Production Location:
Manufactured in Japan by Kubota.
🏆 Awards & Recognition
Recognition
Awards:
N/A – no major awards documented for the B21 specifically; its reputation for reliability is well known.
