Kubota B1700HSD Tractor Illustrated Master Parts List Manual

Kubota B1700HSD Tractor Illustrated Master Parts List Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 24154
Brand
Kubota
Equipment
Lawnmowers
Models covered
Other Wheel Horse Manuals, Wheel Horse
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Kubota
Model:
B1700HSD
Model Variant:
HSD (Hydrostatic Drive)
Production Years:
1990s (approximately 1990-1996)
👋 Introduction
Market Position
Target Audience:
Compact tractor owners, technicians, and DIY enthusiasts
Competitive Analysis
Advantage:
Genuine Kubota parts manual provides exact part numbers and exploded views for accurate ordering and repair
Key Features
Key Feature:
Comprehensive coverage of all tractor components
Key Feature:
Illustrated parts breakdown for easy identification
📋 Manual Details
Coverage Areas
Systems Covered:
Engine (parts), transmission (parts), hydraulics (parts), electrical (parts), chassis, and more
Page Count:
Approximately 400 pages (typical of original manual)
Manual Type
Manual Type:
Illustrated Master Parts List Manual
Language:
English
Format
File Format:
PDF
Delivery Method:
Instant download
📖 Manual Coverage
Systems and Procedures
Engine:
Complete parts list with exploded diagrams for disassembly and reassembly
Transmission:
Parts for hydrostatic transmission, differential, and final drives
Hydraulics:
Hydraulic pump, cylinders, valves, and lines
Electrical:
Starter, alternator, wiring harness, switches, and gauges
Brakes:
Brake parts and adjustments
Steering:
Steering gear and linkage parts
Front Axle:
Front axle assembly and wheel drive components
Rear Axle:
Rear axle and differential parts
PTO:
Power take-off components and drive shafts
3-Point Hitch:
Lift arms, stabilizers, and hydraulic top link
Body and Sheet Metal:
Hoods, fenders, grille, and other cosmetic parts
Operator's Station:
Seat, steering wheel, controls, and instrument panel
Cooling System:
Radiator, fan, and water pump
Fuel System:
Fuel tank, lines, filter, and injection components
Exhaust:
Muffler and exhaust pipe
Tires and Wheels:
Wheels, rims, and tire sizes
Decals:
Warning and instruction decals with part numbers
Parts Ordering:
Exact part numbers and quantities for ordering
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Windows, Mac, Linux, iOS, Android (with PDF reader)
Requirements:
Adobe Acrobat Reader or similar
Searchability:
Searchable text for quick lookup
Print Quality
Print Resolution:
High resolution (300 DPI) for clear detail
Binding and Paper
Binding Type:
Digital
Paper Type:
Digital (can be printed on standard paper)
⚙️ Engine Specifications
Primary Engine
Engine Make:
Kubota
Engine Model:
D1102-B (typically)
Engine Type:
Vertical, water-cooled, 4-cycle diesel
Displacement:
1.1 L (68.9 cu in) approximately
Cylinders:
3
Power Output:
17 horsepower (gross) approximately
Rated RPM:
3000 rpm
Fuel System:
Direct injection (typical)
🔧 Transmission
Standard Transmission
Type:
Hydrostatic (HSD)
Gears:
Infinite forward and reverse
Controls:
Dual pedal speed control
Features
Rear PTO:
Independent or live PTO with 540 rpm
Final Drives:
Heavy-duty gear drive
📐 Dimensions
Exterior
Wheelbase:
Approximately 1430 mm (56.3 in)
Length:
Approximately 2310 mm (91 in)
Width:
Approximately 1240 mm (48.8 in)
Height (to hood):
Approximately 1370 mm (54 in)
Weights
Curb Weight (approx):
Depending on configuration, around 650 kg (1433 lb)
🛡️ Safety Features
Active Safety
Brakes:
Wet disc brakes (typical)
Steering:
Power steering (HSD variant)
Passive Safety
Rollover Protection:
ROPS not included in parts manual; may be dealer-installed
💡 Technology Features
Operator Assistance
Gauges:
Standard analog gauges for engine temperature, fuel, and tachometer
🔧 Maintenance
Service Intervals
Engine Oil:
Replace every 100 hours or annually
Oil Filter:
Replace with engine oil change
Fuel Filter:
Replace every 300 hours or annually
Air Filter:
Inspect every 50 hours; replace as needed
Hydraulic Oil:
Replace every 300 hours or 24 months (check manual)
Transmission Oil:
Replace every 300 hours or 24 months (check manual)
Lubrication
Coolant:
Change every 2 years
Known Issues / Common Wear Items
Hydrostatic pump seals:
May degrade with age, causing leaks
Injector nozzles:
Carbon buildup over time, servicing may be required
📚 Vehicle History
Manufacturer
Manufacturer:
Kubota Corporation
Model Evolution
Predecessor:
Kubota B1700 (non-HSD)
Successor:
Kubota B1700 replaced by later B series models (e.g., B7100, B7400 in some markets)
Production Location
Production Location:
Japan (primarily)
🏆 Awards & Recognition
Recognition
General Recognition:
Kubota B series tractors are known for reliability and durability
