Kubota B1550E Tractor Illustrated Master Parts List Manual

Kubota B1550E Tractor Illustrated Master Parts List Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 24150
Brand
Kubota
Equipment
Tractors
Models covered
Others
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Kubota
Model:
B1550E
Model variant:
B1550E (4WD compact tractor)
Production years:
1980s to mid-1990s (approx.)
👋 Introduction
Market Position
Target audience:
Small farm owners, hobby farmers, and landscaping professionals needing a compact utility tractor.
Market position:
Entry-level to mid-range compact tractor offering reliable performance and versatility in a small package.
Competitive Analysis
Advantage:
Known for durability, ease of operation, and a wide range of compatible implements.
Key Features
Engine:
Liquid-cooled diesel engine for efficient fuel use and long life.
Transmission:
Sliding gear transmission with 8 forward and 4 reverse speeds.
4WD:
Mechanical 4-wheel drive enhances traction on varied terrain.
Hydraulics:
Position control and draft control for precise implement handling.
📋 Manual Details
Manual Overview
Coverage:
Complete parts information for Kubota B1550E tractor, including all systems and components.
Page count:
Approximately 80 pages
Manual type:
Illustrated Master Parts List
Language:
English
File format:
PDF
Delivery method:
Instant download
📖 Manual Coverage
Systems Covered
Engine:
Engine block, cylinder head, pistons, crankshaft, and related components.
Fuel system:
Fuel tank, injection pump, injectors, filters, and lines.
Cooling system:
Radiator, water pump, thermostat, hoses, and fan.
Transmission:
Clutch, gearbox, shafts, gears, and shift mechanisms.
Rear axle and differential:
Differential assembly, axles, and final drives.
Front axle (4WD):
Front drive axle, hub, and steering components.
Hydraulic system:
Hydraulic pump, control valves, lift cylinder, and lines.
Steering:
Manual or hydraulic power steering components.
Brakes:
Disc or drum brakes, mechanical linkage.
Electrical:
Starter motor, alternator, wiring harness, switches, and lights.
Three-point hitch:
Lift arms, top link, sway bars, and associated hardware.
Procedures
Disassembly and assembly:
Step-by-step instructions with reference to part numbers.
Part identification:
Exploded diagrams clearly showing each component and its position.
Part numbers:
Genuine Kubota part numbers for ordering replacements.
Technical Depth
Level of detail:
Designed for parts lookup and precise identification, not step-by-step service procedures.
Parts Information
Quantity:
Quantities specified for each part to help with ordering.
Compatibility:
Covers multiple model variants (standard and 4WD) where applicable.
📊 Manual Specifications
File Format
File type:
PDF
Compatibility:
Works on computers, tablets, and smartphones with PDF reader installed.
Requirements:
Adobe Acrobat Reader or similar PDF viewer.
Searchability:
Searchable text for quick part lookup.
Print Quality
Scan quality:
High-resolution pages for clear reproduction.
Binding and Paper
Binding type:
Digital binding - no physical binding.
Paper type:
N/A - digital product
⚙️ Engine Specifications
Primary Engine
Make and model:
Kubota D905 (or similar)
Type:
Liquid-cooled 4-cycle diesel
Cylinders:
3
Displacement:
0.9 L (approx.)
Power output:
20.5 HP (approx.)
Fuel system:
Indirect injection
Performance
Rated RPM:
3000 RPM (approx.)
Torque:
N/A - not specified
🔧 Transmission
Standard Transmission
Type:
Sliding gear
Forward gears:
8
Reverse gears:
4
Clutch:
Dry single disc
Optional Transmission
Options:
No options offered for this model.
Features
4WD:
Mechanical front-wheel drive option available.
Differential lock:
Provides extra traction when needed.
📐 Dimensions
Exterior
Wheelbase:
Approximately 57 inches (145 cm)
Length:
Approximately 100 inches (254 cm)
Height:
Approximately 60 inches (152 cm)
Width:
Approximately 45 inches (114 cm)
Weights
Curb weight:
Approximately 1600 pounds (726 kg)
🛡️ Safety Features
Ratings
Crash test information:
N/A - off-highway vehicle
Active Features
Brakes:
Internal expanding dry disc brakes.
Steering:
Manual steering standard; power steering optional on some variants.
Passive Features
Seat belt:
Provided for operator safety.
Rollover protective structure:
ROPS may be available as an option.
💡 Technology Features
Infotainment
Audio system:
N/A - no infotainment system on this tractor.
Driver Assistance
Electrical system:
12-volt electrical system for lighting and starting.
Instrumentation:
Basic gauges for engine temperature and fuel.
🔧 Maintenance
Service Intervals
Engine oil:
Change every 50 hours or 6 months, whichever comes first.
Oil filter:
Replace at each oil change.
Fuel filter:
Replace every 100 hours or annually.
Air filter:
Clean every 10 hours, replace every 200 hours or annually.
Hydraulic fluid:
Check level daily; replace every 400 hours.
Coolant:
Replace every 2 years.
Fluid Specifications
Engine oil type:
SAE 10W-30 diesel engine oil (API CC or higher)
Hydraulic fluid type:
Kubota UDT hydraulic fluid or equivalent.
Coolant type:
50/50 mixture of ethylene glycol and water.
Known Issues / Common Wear Items
Common wear parts:
Belts, hoses, filters, and brake discs.
Typical issue:
Shifter linkage wear may cause difficulty changing gears.
📚 Vehicle History
Brand Heritage
Manufacturer:
Kubota Corporation, founded in 1890 in Osaka, Japan.
Known for:
Reliable agricultural and construction equipment.
Model Evolution
Series:
B series compact tractors introduced in the 1970s, evolving with various sub-models.
B1550E:
Part of the B1550 series, offering a balance of power and compact size.
Production Location
Production sites:
Manufactured in Japan; sold globally.
🏆 Awards & Recognition
Recognitions
Awards:
N/A - no specific awards found for this model.
