John Deere 4055 4255 4455 Tractors Operation & Tests Technical Manual(TM1459)

John Deere 4055 4255 4455 Tractors Operation & Tests Technical Manual(TM1459)

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 103049
Brand
John Deere
Equipment
Crawler Tractors
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
John Deere
Model:
4055, 4255, 4455
Model Variant:
Standard tractors with various configurations
Production Years:
1988-1992
👋 Introduction
Market Position
Target Audience:
Farmers and operators requiring dependable high-horsepower agricultural tractors.
Market Segment:
Row-crop and utility tractors in the 100-135 HP range.
Competitive Analysis
Advantage:
Renowned for durability, advanced transmission options, and reliable performance in demanding conditions.
Key Features
Engine:
John Deere 400 Series Diesel Engines.
Transmission:
QUAD-RANGE and Power Shift transmissions.
Hydraulics:
Advanced hydraulic system for efficient implement operation.
📋 Manual Details
Reference
Manual Number:
TM1459
Coverage
Models Covered:
John Deere 4055, 4255, 4455
Format
Pages:
Approximately 1400 pages (as per similar John Deere manuals).
Manual Type:
Operation & Tests Technical Manual
Language:
English
File Format:
PDF
Delivery Method:
Instant Download
📖 Manual Coverage
Systems Covered
Engine Operation:
Theory, operation, and testing procedures.
Fuel and Air Systems:
Injection, filters, air intake, and exhaust.
Transmissions:
QUAD-RANGE and Power Shift transmissions.
Power Take-Off (PTO):
PTO operation and testing.
Axles and Differentials:
Front and rear axles, differential lock.
Steering and Brakes:
Hydraulic steering and brake systems.
Hydraulic System:
Pump, valves, and cylinders for implement control.
Electrical System:
Wiring diagrams and component operation.
Operator Station:
Controls, gauges, and cab diagnostics.
Safety Section:
Dedicated safety information and precautions.
Procedures
Diagnostics:
Step-by-step troubleshooting procedures.
Testing:
Test procedures for systems and components.
Theory of Operation:
Detailed explanation of system function.
Adjustments:
Specifications and adjustment procedures.
Technical Depth
Target Audience:
Technicians and experienced DIY owners.
Content Level:
Advanced technical manual with in-depth information.
Parts Information
Parts Data:
N/A - parts numbers not fully listed in operation and tests manual.
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
All devices with PDF reader.
Requirements:
PDF reader software (free).
Searchability:
Fully searchable if original PDF includes text layer; this manual is typically scanned and OCR'd, offering searchable text.
Print Quality
Resolution:
High resolution scan, legible for printing.
Binding
Binding Type:
Digital (no physical binding)
Paper Type
Paper Type:
N/A - digital download
⚙️ Engine Specifications
Engine Options
Engine Model:
John Deere 400 Series Diesel Engines.
Displacements:
Varied across models: 404 cu in (6.6 L) for 4055, 466 cu in (7.6 L) for 4255, 466 cu in for 4455 (turbocharged).
Power Range:
Approximately 105 to 135 HP at rated engine speed.
Performance
Torque Rise:
Approximately 20% (typical for 400 series).
Fuel System
Fuel Type:
Diesel
Injection System:
Direct injection with rotary pump (as used in 400 series).
🔧 Transmission
Options
Standard Transmission:
QUAD-RANGE: 16 forward and 6 reverse gears.
Optional Transmission:
Power Shift: 15 forward and 4 reverse gears (full powershift).
Features
Shifting:
Power Shift allows shifting under load without clutching.
Control:
Electro-hydraulic control for convenience.
PTO Speed:
Independent PTO with 540/1000 rpm options.
📐 Dimensions
Exterior Measurements
Wheelbase:
Approximately 108.7 inches (276 cm) (varies by model/tire size).
Length:
Approximately 168 inches (427 cm) from bumper to drawbar.
Width:
Varies with tire tread, roughly 90 inches (229 cm).
Height:
Varies with cab, roughly 113 inches (287 cm).
Weight
Curb Weight:
Approximately 10,500 lbs (4,763 kg) for 4055, heavier for larger models.
🛡️ Safety Features
Ratings
Safety Ratings:
N/A - not rated (tractor safety not crash tested).
Active Features
Lighting:
Standard headlights and work lights for visibility.
Warning Systems:
Instrument panel warning lights for engine oil pressure, coolant temperature, etc.
Passive Features
Rollover Protection:
Cab should meet ROPS standards if equipped with ROPS.
Seat Belt:
Seat belts are installed in cab tractors.
💡 Technology Features
Infotainment
Audio System:
AM/FM radio typically installed in cab models.
Driver Assistance
Monitoring:
Digital dashboards available in later years.
Guidance:
N/A - no GPS or auto-guidance (era-specific).
🔧 Maintenance
Service Intervals
Engine Oil:
Change engine oil every 100 hours (severe service more often).
Hydraulic Oil:
Replace hydraulic/transmission oil every 400 hours (or annually).
Coolant:
Check level daily; replace every 2 years.
Fluid Specifications
Engine Oil:
API service classification CC/SE or CD/SF, viscosity 10W-30 or 15W-40.
Hydraulic/Transmission Oil:
John Deere Hy-Gard (low viscosity) or equivalent.
Coolant:
Ethylene glycol based with low silicate content.
Known Issues
Common Wear Items:
Belts, hoses, seals, filters, fuel injectors, clutch and brake components.
📚 Vehicle History
Brand Heritage
Manufacturer:
John Deere (Deere & Company), founded in 1837.
Model Evolution
Series:
The 55 Series succeeded the 40 Series, later replaced by the 60 Series.
Production Location
Plant Location:
Waterloo, Iowa, USA (general John Deere tractor plant).
🏆 Awards & Recognition
Recognitions
Industry Recognition:
N/A - this model series not known to have specific awards.
