IAME PARILLA 125cc 125 LEOPARD TAG Engine 2003

IAME PARILLA 125cc 125 LEOPARD TAG Engine 2003

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 23565
Brand
Iame Parilla
Equipment
Engines
Models covered
125
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
ASSEMBLY INSTRUCTIONS and USER MANUAL GENERAL DESCRIPTION OF THE \"LEOPARD\" ENGINE CHARACTERISTICS OF THE \"LEOPARD\" ENGINE – OPERATIONAL LIMITS 1- Contents of the packing 2- Motor identification Number 3- Preparation and installation of the engine on the chassis 3.1 Install the water cooling system 3.2 Exhaust header assembly 3.3 Preparation and installation of the motor-mount 3.4 Install the carburetor 3.5 Install the engine on the chassis 3.6 Install the clutch cover with H.T. coil 3.7 Installation and connection of the power pack box 3.8 Electrical connections on the engine 3.9 Installation of the intake silencer 3.10 Install the exhaust 4- GASOLINE and OIL 5- Carburetor Adjustment guide 6- Starting and stopping the engine 7- Engine break-in 8-Inlet silencer 9- Exhaust system 10- Centrifugal clutch 11- Instructions for the assembly/disassembly of the clutch 12- Battery 13- Spark plug and thermal degree 14- Choice of the best sprocket ratio 15- Scheduled maintenance 16- Troubleshooting 17- Engine and accessories preservation Attachments: - Fastener Torque Table - Wiring diagram

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
