Ford New Holland 4500 3 CYLINDER INDUSTRIAL Tractor MASTER ILLUSTRATED Parts List Manual BOOK

Ford New Holland 4500 3 CYLINDER INDUSTRIAL Tractor MASTER ILLUSTRATED Parts List Manual BOOK

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 27760
Brand
New Holland
Equipment
Tractors
Models covered
4500
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Ford New Holland
Model:
4500
Model Variant:
3 Cylinder Industrial Tractor
Production Years:
1968-1975 (approx.)
👋 Introduction
Market Position
Target Audience:
Technicians, DIY owners, and equipment restorers
Competitive Advantage:
Comprehensive parts identification with Ford New Holland factory specifications
Key Features:
Master illustrated parts list covering all major systems
📋 Manual Details
Format
Coverage Areas:
Complete tractor including engine, transmission, hydraulics, electrical, and sheet metal
Page Count:
Approximately 100-150 pages
Manual Type:
Parts list manual
Language:
English
File Format:
PDF
Delivery Method:
Instant download
📖 Manual Coverage
Systems Covered
Engine:
Complete engine parts with part numbers and diagrams
Fuel System:
Fuel tank, lines, injection pump, injectors, filters
Electrical System:
Alternator, starter, wiring harness, switches, lights
Cooling System:
Radiator, water pump, thermostat, hoses
Clutch:
Clutch assembly and controls
Transmission:
Gearbox, shift mechanisms, PTO
Rear Axle:
Axle housing, differential, and final drives
Front Axle:
Front axle and steering components
Steering System:
Steering gear, tie rods, and power steering components
Brake System:
Brake shoes, drums, and linkage
Hydraulics:
Hydraulic pump, valves, lift cover, cylinders
3-Point Hitch:
Lift arms, top link, and related hardware
PTO:
Power take-off assembly
Wheels and Tires:
Front and rear wheels, rims, and tire sizes
Body and Sheet Metal:
Hood, grille, fenders, and brackets
Controls:
Pedals, levers, cables, and linkage
Procedures and Technical Depth
Type of Content:
Parts identification with diagrams and part numbers
Installation Reference:
Parts diagrams assist in assembly and disassembly
Technical Depth:
Moderate - suitable for parts replacement and identification
Parts Information:
Original Ford New Holland genuine part numbers
📊 Manual Specifications
File and Format
File Type:
PDF
Compatibility:
All devices with PDF reader
Requirements:
Adobe Acrobat Reader or similar
Searchability:
Digital searchable pages for quick part lookup
Print Quality:
High resolution (300 dpi) for clear diagrams
Binding Type:
Digital (no physical binding)
Paper Type:
N/A - digital delivery only
⚙️ Engine Specifications
Engine Specifications
Primary Engine:
Ford 3-cylinder diesel
Displacement:
3.9 liters (approx.)
Power Output:
47-52 hp (approx.)
Fuel System:
Direct injection, mechanical lift pump
Cooling Type:
Liquid-cooled
🔧 Transmission
Transmission
Standard Transmission:
8-speed manual (4x2 with high-low)
Optional Transmission:
Not specified
Clutch Type:
Dry single plate
PTO Speeds:
540 RPM (rear)
📐 Dimensions
Dimensions and Weights
Wheelbase:
Approximately 2050 mm (80.7 in)
Length:
Approximately 3450 mm (135.8 in)
Curb Weight:
Approximately 2700 kg (5950 lb)
🛡️ Safety Features
Safety Features
Rollover Protection:
Not available; operator protection improved with ROPS if installed
Active Features:
None
Passive Features:
Operator protection depends on ROPS (common aftermarket or dealer-installed)
💡 Technology Features
Technology Features
Infotainment:
None
Driver Assistance:
None - manual controls only
🔧 Maintenance
Maintenance
Service Intervals:
Engine oil: every 100 hrs; hydraulic fluid: every 1000 hrs
Fluid Specifications:
Engine oil: 10W-30 or 15W-40 diesel engine oil
Hydraulic Fluid:
Ford New Holland or equivalent Universal Tractor Trans/Hydraulic Fluid
Common Wear Items:
Tires, hydraulic hoses, steering components, water pump, clutch plates
📚 Vehicle History
Vehicle History
Manufacturer:
Ford Motor Company / Ford Tractor (later New Holland)
Model Evolution:
Part of Ford's 4000 series industrial line, introduced in 1968
Production Location:
Highland Park, Michigan, USA (and possibly other plants)
🏆 Awards & Recognition
Awards and Recognition
Model Era Recognition:
Known for reliability; no formal awards documented

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
