Electrical Schematic-Case Magnum Tractors MX200 MX220 MX240

Electrical Schematic-Case Magnum Tractors MX200 MX220 MX240

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 173455
Brand
CASE
Equipment
Tractors
Models covered
Case, Magnum MX Series
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Case IH
Model:
Magnum
Model Variants:
MX200, MX220, MX240
Production Years Covered:
1996-2002
👋 Introduction
Market Position
Target Audience:
Farmers, agricultural contractors, and equipment technicians operating or maintaining Case IH Magnum tractors.
Segment:
High-horsepower row crop tractors
Competitive Advantage:
Known for robust build, operator comfort, and strong hydraulic capacity compared to contemporaries.
Key Feature:
Full electrical schematics for diagnosis and repair of MX series tractors.
📋 Manual Details
Coverage
Coverage Areas:
Electrical system schematics for MX200, MX220, MX240
Page Count:
4 pages
Manual Type:
Electrical Schematic
Language:
English
File Format:
PDF
Delivery Method:
Instant download
📖 Manual Coverage
Electrical Systems
Starting and Charging:
Schematics for starter motor, alternator, and battery circuits.
Lighting:
Headlight, taillight, work light, and warning light circuits.
Instrumentation:
Gauges, indicators, and warning lamps.
Cab Controls:
AC/Heater controls, wiper, and horn circuits.
Engine Controls:
Fuel shutoff, throttle position sensor, and ECM connections.
Transmission Controls:
Shuttle shift, range selection, and related sensors.
Hydraulic Controls:
Solenoid valves, pressure switches, and position sensors.
PTO Controls:
Switch and relay circuits for rear PTO engagement.
Hitch Controls:
Electro-hydraulic hitch position and draft sensing.
Communication:
CAN bus and diagnostic connectors.
Fuses and Relays:
Locations and ratings of fuses and relays.
Wiring Harness:
Connector and splice locations.
Procedures
Diagnostic Steps:
Troubleshooting flowcharts for common electrical faults.
Testing Methods:
Voltage, continuity, and resistance checks.
Component Checks:
Solenoid, sensor, and switch testing.
Technical Depth
Level:
Schematic-level detail, no component repair instructions.
Part Numbers:
No part numbers listed.
📊 Manual Specifications
Format
File Format:
PDF
Compatibility:
Any PDF reader (Adobe, Foxit, etc.)
Requirements:
No special software needed.
Searchability:
Text searchable if the PDF contains text layers.
Print Quality:
Monochrome line drawings, print at 300 DPI.
Binding Type:
Digital
Paper Type:
N/A - Digital download
⚙️ Engine Specifications
Primary Engine
Engine Options:
Case IH 5.9L and 8.3L turbocharged diesel engines
Power Range:
Approximately 200-240 HP (varies by model)
Performance:
High torque rise for heavy tillage
Fuel System:
Mechanical or electronic fuel injection depending on model year
🔧 Transmission
Configuration
Standard Transmission:
Full powershift with 18 forward and 4 reverse speeds (approximate)
Optional Transmission:
Creeper speeds available
Features:
Electronic shift control and smooth clutch engagement
📐 Dimensions
Exterior
Wheelbase:
Approximately 3.2 m (126 in)
Length:
Approximately 5.7 m (224 in)
Weights
Curb Weight:
Approximately 10,000 kg (22,000 lb)
🛡️ Safety Features
Ratings
Crash Test Information:
N/A - Tractors are not crash tested
Active Features
Braking:
Hydraulic wet disc brakes
Lighting:
Road lighting for transport
Passive Features
Cab Protection:
ROPS (Roll-Over Protective Structure) cab
💡 Technology Features
Infotainment
Audio System:
Basic AM/FM radio
Driver Assistance
Guidance:
N/A - Not available on models of this era
Hitch Draft Control:
Electronic hitch control for consistent depth
🔧 Maintenance
Intervals
Engine Oil:
Every 250 hours (typical)
Hydraulic Fluid:
Every 1000 hours (typical)
Fluid Specifications
Engine Oil:
API CI-4 or higher, 15W-40
Transmission/Hydraulic:
Case IH Hy-Tran Ultraction or equivalent
Coolant:
Ethylene glycol based
Known Issues
Common Wear:
Electrical connector corrosion, wiring chafing, and alternator wiring failures
📚 Vehicle History
Heritage
Manufacturer:
Case IH (CNH Industrial)
Model Evolution:
Introduced in 1996, superseded by MX Magnum series later
Production Location:
Racine, Wisconsin, USA
🏆 Awards & Recognition
Recognitions
Awards:
N/A - No specific awards found for this model

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
