David Brown 1490 Tractor Workshop Service Manual for Repair

David Brown 1490 Tractor Workshop Service Manual for Repair

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 79338
Brand
David Brown
Equipment
Tractors
Models covered
1490
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
David Brown
Model:
1490
Variant:
Standard model
Production Years:
1972–1979
👋 Introduction
Market Position
Target Audience:
Farmers, agricultural contractors, and equipment enthusiasts
Market Segment:
Utility tractors (approx. 70 hp class)
Competitive Analysis
Advantages:
Robust construction, reliable engine, ease of maintenance, strong hydraulic capacity for its class
Key Features
Engine:
4-cylinder diesel, direct fuel injection
Transmission:
Dual-range with 12 forward and 4 reverse gears
Hydraulics:
Implement linkage with position and draft control
PTO:
Independent rear PTO with 540 rpm
Cab Option:
Available with safety cab for operator protection
📋 Manual Details
Coverage
Models Covered:
David Brown 1490
Coverage Area:
Complete workshop manual: engine, transmission, hydraulics, electrical, and more
Specifications
Page Count:
Over 300 pages (approx.)
Manual Type:
Workshop Service Manual for Repair
Language:
English
File Format:
PDF
Delivery:
Instant download
📖 Manual Coverage
Systems Covered
Engine:
Complete overhaul and repair procedures
Transmission:
Gearbox, clutch, drive shafts, differential
Hydraulics:
Pump, lift system, controls
Electrical System:
Wiring diagrams, components, troubleshooting
Steering:
Mechanical and hydraulic power steering (if equipped)
Brakes:
Service and parking brakes
PTO:
System and driven components
Cooling System:
Radiator, water pump, thermostat
Fuel System:
Injection pump, injectors, filters
Exhaust System:
Manifold, muffler
Body and Sheet Metal:
Removal and installation of panels
Procedures Included
Removal and Installation:
Step-by-step instructions for all major components
Disassembly and Assembly:
Detailed sequences with torque specs
Troubleshooting:
Diagnostic tables for common faults
Adjustment:
Settings for clutches, brakes, valves, etc.
Service Data:
Technical specifications for all systems
Technical Depth
Level:
Detailed enough for DIY and professional technicians
Illustrations:
Line drawings and diagrams
Parts Information
Part Numbers:
Reference to David Brown genuine part numbers where applicable
📊 Manual Specifications
File Format
File Type:
PDF (Portable Document Format)
Compatibility:
PC, Mac, mobile devices, any PDF reader
Requirements:
Modern web browser or PDF reader
Searchability:
Full text search (digital PDF)
Print Details (for physical manual)
Print Quality:
High-resolution images (if printed)
Binding Type:
Digital (no physical binding)
Paper Type:
N/A - digital download
⚙️ Engine Specifications
Engine Options
Standard Engine:
David Brown 4-cylinder diesel, direct injection
Performance
Displacement:
3.6 L (approx.)
Power Output:
Approximately 67 hp (DIN) at rated rpm
Fuel System
Type:
Direct fuel injection
Injection Pump:
CAV rotary type
Capacity:
Approximately 13.6 gallons (approx.)
🔧 Transmission
Standard Transmission
Type:
Dual-range constant mesh
Gears:
12 forward, 4 reverse
Features
Clutch:
Dry single-plate
PTO:
Independent rear, 540 rpm
📐 Dimensions
Exterior Dimensions
Wheelbase:
Approximately 77.2 inches
Length (without 3PL):
Approximately 127.2 inches
Weight
Curb Weight (approx):
Approximately 5,290 lbs
🛡️ Safety Features
Ratings and Safety Testing
Safety Assessments:
No independent crash test ratings typical for tractors
Active Safety Features
Operator Protective Structure:
Foldable or fixed safety cab available
Lighting:
Work lights for visibility
Passive Safety Features
Brakes:
Independent wheel brakes for tight turns
Transmission Park:
Manual park position
💡 Technology Features
Infotainment
Audio System:
N/A - not equipped
Driver Assistance
Assistance Systems:
Not applicable (vintage model)
🔧 Maintenance
Service Intervals
Engine Oil:
Every 100 hours or annually, whichever comes first
Transmission/Hydraulic Oil:
Every 600 hours or as specified
Coolant:
Change every 1000 hours or per manual
Fuel Filter:
Replace every 200 hours
Fluid Specifications
Engine Oil:
SAE 10W-30 or 10W-40 (API CC/CD)
Transmission Oil:
SAE 80W-90 or equivalent
Hydraulic Oil:
UTF (Universal Tractor Fluid) or equivalent
Coolant:
Ethylene glycol based, mixed correctly
Known Issues / Common Wear Items
Common Wear Items:
Clutch plates, brakes, hydraulic seals, injector nozzles
Known Issues:
Hydraulic pump noise if oil low; starter issues from corrosion
📚 Vehicle History
Brand Heritage
Manufacturer:
David Brown Ltd.
Heritage:
Part of the David Brown tractor line, known for robust agricultural machinery
Model Evolution
Predecessor:
David Brown 1200
Successor:
Later replaced by the 1490 Selectamatic evolution
Production Location
Factory:
Metham, West Yorkshire, England
🏆 Awards & Recognition
Recognition
Industry Awards:
No specific awards documented for this model
Legacy
Legacy:
Recognized for durability and reliability among classic tractors
