Claas AXION 810-850 Hexashift-C.I.S. Operation Manual

Claas AXION 810-850 Hexashift-C.I.S. Operation Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 94885
Brand
Claas
Equipment
Tractors
Models covered
Axion Series
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Claas
Model:
AXION 800 series
Model Variant:
810, 820, 830, 840, 850
Production Years:
2013-2017 (approx.)
👋 Introduction
Market Position
Target Audience:
Farmers, contractors, and operators requiring high-horsepower tractors for heavy tillage, haulage, and field operations.
Competitive Advantage:
Hexashift continuously variable transmission (CVT) with C.I.S. (Claas Intelligent Systems) for efficient power delivery and ease of use.
Key Features
Engine:
6.7L or 8.8L (depending on model) DPS engines with high torque reserve.
Transmission:
Hexashift continuous variable transmission (CVT) with 24 forward and 24 reverse gears.
Cab:
Spacious cab with excellent visibility, low noise levels, and intuitive controls.
Hydraulics:
Up to 220 L/min hydraulic flow for demanding implements.
📋 Manual Details
Coverage
Models Covered:
Claas AXION 810, 820, 830, 840, 850 with Hexashift-C.I.S.
Topics Covered:
Operation, controls, maintenance, safety, troubleshooting, and specifications.
Format
Page Count:
Approximately 200-300 pages.
Manual Type:
Operation manual (not service/repair).
Language:
English
File Format:
PDF (portable document format).
Delivery Method:
Instant download after purchase.
📖 Manual Coverage
Systems Covered
Engine:
Description of engine components, operating principles, and basic checks.
Transmission and Drivetrain:
Hexashift CVT operation, gear ranges, differential lock, and four-wheel drive.
Hydraulic System:
Hydraulic controls, implement hitch, and external hydraulic valves.
Electrical System:
Battery, alternator, fuses, and lighting.
Cab and Climate Control:
Cab controls, air conditioning, heating, and ventilation.
Hitch and PTO:
Three-point hitch operation, PTO speed selection, and shaft engagement.
Brakes and Steering:
Service and parking brakes, hydraulic steering system.
Wheels and Tires:
Tire sizes, pressures, and wheel bolt torque.
Procedures Included
Operating Instructions:
Step-by-step guidance for starting, driving, and operating implements.
Controls and Instruments:
Description of all levers, switches, and dashboard indicators.
Maintenance Checks:
Daily and periodic checks for fluid levels, filters, and belts.
Troubleshooting:
Common problems and solutions.
Safety Instructions:
Safety warnings and precautions.
Technical Depth
Depth:
Designed for operators; covers operation and routine maintenance but not detailed repair or overhaul procedures.
Parts Information:
May include exploded views and part numbers for common service items.
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Works on any device with a PDF reader (PC, Mac, tablet, smartphone).
Requirements:
Adobe Acrobat Reader or equivalent.
Searchability:
Text is searchable if the PDF has an OCR layer.
Print Quality
Print Resolution:
High resolution (300 DPI) for clear diagrams and text.
Binding and Paper
Binding Type:
Digital - no physical binding.
Paper Type:
N/A - digital format.
⚙️ Engine Specifications
Engine Options and Performance
Engine Models:
AXION 810: 6.7L DPS; AXION 820/830/840/850: 8.8L DPS (exact models may vary).
Power Range:
Up to 290 hp (depending on model, with boost).
Torque:
High torque reserve for demanding operations.
Emissions:
Meets Tier 4 final / Stage IV emission standards (with SCR and DPF).
Fuel System
Fuel Type:
Diesel
Fuel Injection:
Common rail direct injection.
Fuel Capacity:
Approximately 400-500 liters (depending on model).
🔧 Transmission
Standard Transmission
Type:
Hexashift continuously variable transmission (CVT).
Gears:
24 forward and 24 reverse ratios (within 4 ranges).
Operation:
Fully automatic or manual mode with driver override.
Optional Transmission
Available Options:
N/A - Hexashift is standard on all models.
Features
C.I.S.:
Claas Intelligent Systems manage transmission and engine for optimal efficiency.
Cruise Control:
Standard with automatic speed control.
Shuttle:
Power shuttle for direction changes.
📐 Dimensions
Exterior
Wheelbase:
Approximately 2.95 meters (varies by model).
Length:
Approximately 5.8 meters (with standard weights).
Width:
Variable depending on tire width.
Height:
Approximately 3.3 meters to top of cab.
Weights
Curb Weight:
Approximately 9,500-10,500 kg depending on model and equipment.
Max Permissible Weight:
Up to 13,000-14,000 kg (depending on model).
🛡️ Safety Features
Ratings and Crash Tests
Crash Test Rating:
N/A - agricultural tractors are not typically crash-tested.
Active Safety Features
Braking System:
Hydraulic disc brakes on all four wheels with anti-lock braking system (optional).
Steering:
Hydrostatic power steering for precise control.
Lighting:
Work lights for visibility, including optional front and rear LED lights.
Passive Safety Features
ROPS:
Rollover Protective Structure (ROPS) certified cab.
Seatbelt:
Operator seatbelt standard.
Emergency Exit:
Second emergency exit (rear window).
💡 Technology Features
Infotainment
Audio System:
AM/FM radio with Bluetooth connectivity (optional).
Display:
Color touchscreen (depending on model) for tractor and implement control.
Driver Assistance
Guidance Systems:
Optional GPS steering assist / autopilot.
Telematics:
Claas Telematics for fleet management (optional).
ISOBUS:
ISOBUS Class III for implement communication.
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 500 hours (or annually, whichever comes first).
Hydraulic Oil Change:
Every 2000 hours or as indicated by condition.
Fuel Filter Replacement:
Every 1000 hours.
Air Filter Cleaning:
Every 50 hours or as needed.
Coolant Fluid Change:
Every 5000 hours or 5 years.
Fluid Specifications
Engine Oil:
SAE 10W-30 (API CJ-4 or similar).
Hydraulic Fluid:
Claas Hydraulic Fluid or equivalent (ISO 11158 HV).
Transmission Fluid:
Claas Hexashift Transmission Oil (special).
Coolant:
Long-life coolant (glysantin G48 or equivalent).
Known Issues
Common Wear Items:
Belts, filters, hydraulic seals.
Potential Issues:
Some reports of electrical connector corrosion and transmission software glitches; updated software available.
📚 Vehicle History
Heritage
Manufacturer:
Claas KGaA mbH, a German agricultural machinery manufacturer.
Model Evolution:
AXION 800 series succeeded the AXION 800 series (original), incorporating new engines (DPS) and Hexashift CVT with C.I.S.
Production
Production Location:
Produced in Paderborn, Germany (Claas tractor plant).
🏆 Awards & Recognition
Recognitions
Tractor of the Year:
AXION 800 series won 'Tractor of the Year 2014' in the high horsepower category.
Machine of the Year:
AXION 800 received an award at Agritechnica for its innovative transmission concept.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
