Case I.h. 1290 (david Brown) Tractor Service Repair Workshop Manual

Case I.h. 1290 (david Brown) Tractor Service Repair Workshop Manual

$0.00
$0.00
Sale Sold out
Shipping calculated at checkout.
Machine data plate
Brand
Case
Equipment
Tractors
Models covered
1290
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you โ€” re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
๐Ÿท๏ธ Basic Information
Identification
Make:
Case IH (David Brown)
Model:
1290
Model Variant:
Standard
Production Years:
1978-1983
๐Ÿ‘‹ Introduction
Market Position
Target Audience:
Farmers and contractors needing a versatile mid-range tractor for tillage, hauling, and loader work.
Competitive Analysis
Advantage:
Robust David Brown build quality with proven mechanical simplicity, offering easy maintenance and reliable performance in its power class.
Key Features
Key Features:
Diesel engine, synchromesh transmission, live hydraulics, power steering (optional), and a comfortable operator platform.
๐Ÿ“‹ Manual Details
Coverage & Format
Coverage Areas:
All major systems: engine, fuel, cooling, lubrication, transmission, hydraulics, electrical, braking, and steering.
Page Count:
N/A - not specified for this manual
Manual Type:
Factory service repair manual
Language:
English
Format:
PDF (instant download)
๐Ÿ“– Manual Coverage
Systems Covered
Engine Mechanical:
Engine disassembly, inspection, and overhaul.
Fuel System:
Fuel tank, lines, injection pump, injectors, and governor.
Cooling System:
Radiator, water pump, thermostat, and hoses.
Lubrication System:
Oil pump, filter, and pressure checks.
Transmission:
Gearbox, synchromesh units, shafts, and bearings.
Hydraulics:
Hydraulic pump, control valves, cylinders, and three-point linkage.
Electrical System:
Wiring diagrams, starter motor, alternator, and lights.
Braking System:
Mechanical and hydraulic brakes, adjustments, and overhaul.
Steering System:
Manual and power steering components, adjustment, and repair.
Procedures Included
Maintenance:
Scheduled service procedures with intervals and specifications.
Troubleshooting:
Diagnostic charts and fault-finding guides.
Disassembly & Assembly:
Step-by-step instructions for major components.
Overhaul:
Complete engine and transmission rebuild procedures.
Technical Depth
Diagrams:
Detailed illustrations and exploded views.
Specifications:
Torque settings, clearances, and fluid capacities.
Parts Information:
Part numbers and reference for ordering original components.
๐Ÿ“Š Manual Specifications
File Format
File Type:
PDF
Compatibility:
All devices that support PDF viewing (Windows, Mac, iOS, Android).
Requirements:
PDF reader software.
Searchability:
Searchable text for quick lookup.
Print Quality
Print Quality:
High resolution, 300 DPI.
Binding & Paper
Binding Type:
Digital (no physical binding)
Paper Type:
N/A - digital product
โš™๏ธ Engine Specifications
Primary Engine
Engine Type:
4-cylinder diesel (David Brown/IH)
Displacement:
3.6 L (approx.)
Power:
62 hp (46 kW) PTO (approx.)
Fuel System:
Direct injection with inline injection pump.
๐Ÿ”ง Transmission
Standard Transmission
Type:
8 forward and 4 reverse (standard)
Features:
Synchromesh on main gear shift for smoother shifting.
Optional Transmission
Optional Type:
Available with power shuttle or creeper gears on some models.
๐Ÿ“ Dimensions
Exterior
Wheelbase:
Approximately 2,180 mm (86 in)
Length:
Approximately 3,500 mm (138 in)
Weights
Curb Weight:
Approximately 3,180 kg (7,010 lb)
๐Ÿ›ก๏ธ Safety Features
Ratings
Crash Test Information:
N/A - not applicable for agricultural tractors.
Active Features
Brakes:
Dual-circuit hydraulic brakes.
Steering:
Manual steering standard; power steering optional.
Passive Features
Rollover Protection:
Roof and roll bar available; safety cab optional.
Seat Belt:
Provided when cab is installed.
๐Ÿ’ก Technology Features
Infotainment
Audio System:
N/A - basic tractor without entertainment features.
Driver Assistance
Differential Lock:
Mechanical differential lock engaged via foot pedal.
PTO:
Independent PTO with multiple speeds.
Hydraulics:
Position and draft control for three-point linkage.
๐Ÿ”ง Maintenance
Service Intervals
Engine Oil:
Every 100 hours or 6 months.
Oil Filter:
At each oil change.
Hydraulic Fluid:
Check level every 10 hours; replace every 1,000 hours or annually.
Coolant:
Replace every 2 years.
Fluid Specifications
Engine Oil:
SAE 15W-40 (API CF or higher).
Transmission & Hydraulic Oil:
IH Hy-Tran or equivalent.
Coolant:
Ethylene glycol based 50/50 mix.
Known Issues & Common Wear Items
Injectors:
Nozzle wear common; inspect and replace as needed.
Hydraulic Pump:
Seals may wear over time.
Electrical Contacts:
Corrosion in wiring connections due to age.
Brake Linings:
Inspect regularly for wear.
๐Ÿ“š Vehicle History
Brand Heritage
Manufacturer:
David Brown Ltd., later Case IH.
Heritage:
Built on the solid reputation of David Brown tractors, known for engineering excellence.
Model Evolution
Predecessor:
David Brown 1290 was introduced in the David Brown Selectamatic series.
Successor:
Continued in Case IH lineup as the 1290, later replaced by models like the 1390.
Production Location
Production Location:
Metham, England (David Brown factory), and later produced under Case IH.
๐Ÿ† Awards & Recognition
Recognitions
Awards:
No specific awards documented for this model.
Era Recognition:
Recognized as a reliable and cost-effective tractor in its class during the late 1970s and early 1980s.
