Case IH 275 Tractor Workshop Service Repair Manual

Case IH 275 Tractor Workshop Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 61666
Brand
CASE
Equipment
Tractors
Models covered
275, Case
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Case IH
Model:
275
Model Variant:
Agricultural tractor
Production Years:
1974-1983
👋 Introduction
Market Position
Target Audience:
Farmers and contractors needing a reliable utility tractor for general farm work
Market Segment:
Utility tractors, 60-80 hp range
Competitive Analysis
Advantage:
Known for rugged construction and ease of maintenance
Key Features
Engine:
Diesel or gasoline options available
Transmission:
Multiple speeds and optional creeper gears
Hydraulics:
Category II three-point hitch
📋 Manual Details
Coverage
Models Covered:
Case IH 275 tractor, all variants
Manual Specifications
Pages:
Approximately 800 pages
Type:
Full service repair manual
Language:
English
File Format:
PDF
Delivery Method:
Instant digital download
📖 Manual Coverage
Systems Covered
General Information:
Model identification, specifications
Engine:
Complete engine overhaul procedures
Fuel System:
Carburetor and fuel injection pump details
Electrical System:
Wiring diagrams, starter, alternator
Clutch:
Adjustment and replacement
Transmission:
Disassembly, repair, assembly
Rear Axle and PTO:
Service and troubleshooting
Hydraulic System:
Pump, valves, cylinders, hitch
Steering:
Manual and power steering overhaul
Brakes:
Service and adjustment
Wheels and Tires:
Sizes and pressures
Procedures Included
Troubleshooting:
Diagnostic guides for common faults
Removal and Installation:
Step-by-step instructions
Overhaul:
Complete rebuild procedures
Adjustment:
Specifications and procedures
Testing:
Inspection and testing methods
Technical Depth
Level:
Comprehensive with detailed diagrams and specifications
Suitable For:
Experienced mechanics and DIY owners
Parts Information
Part Numbers:
Reference numbers for replacement parts
Exploded Views:
Illustrated parts breakdowns
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Any device with a PDF reader
Searchability:
Searchable text
Print Quality
Print Quality:
High-resolution images and diagrams
Binding Type:
Digital
Paper Type:
N/A - digital download
⚙️ Engine Specifications
Engine Options
Standard Engine:
Case 4-cylinder diesel, 219 cu in (3.6 L)
Optional Engine:
Case 4-cylinder gasoline, 219 cu in (3.6 L)
Power Output:
Approximately 65 hp (48 kW) (diesel)
Performance
Rated RPM:
2200 rpm
Torque:
Not available
Fuel System:
Direct injection for diesel, carburetor for gasoline
Cooling:
Liquid-cooled
🔧 Transmission
Transmission Options
Standard Transmission:
8-speed manual (8F/2R)
Optional Transmission:
12-speed manual with creeper gears
Features
Clutch:
Dry disc
Gear Shifting:
Manual
PTO Speeds:
540 and 1000 rpm
📐 Dimensions
Exterior Dimensions
Wheelbase:
91.3 inches (2320 mm)
Length (Overall):
163.8 inches (4160 mm)
Weight
Curb Weight:
Approximately 8,600 lbs (3,900 kg)
🛡️ Safety Features
Safety Ratings
Crash Test Rating:
N/A - not applicable for tractors
Active Features
Steering:
Manual or power-assisted
Brakes:
Hydraulic disc brakes
Rollover Protection:
ROPS available (optional factory/aftermarket)
Passive Features
Seat Belt:
Provided with ROPS
💡 Technology Features
Infotainment
Audio System:
Not available - basic agricultural tractor
Driver Assistance
Precision Farming:
N/A - not equipped
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 100 hours or annually
Transmission Oil Change:
Every 500 hours
Hydraulic Oil Change:
Every 500 hours
Coolant Change:
Every 1000 hours or 2 years
Fluid Specifications
Engine Oil:
SAE 15W-40 (API CF or higher)
Transmission Oil:
SAE 30 (or Case IH Hy-Tran fluid)
Hydraulic Fluid:
Case IH Hy-Tran or compatible
Coolant:
Ethylene glycol based
Known Issues and Wear Items
Electrical:
Wiring harness may deteriorate
Clutch:
May need adjustment at higher hours
Injector Nozzles:
May require cleaning or replacement
Water Pump:
Can leak and require replacement
📚 Vehicle History
Brand Heritage
Manufacturer:
Case IH (International Harvester)
Model Evolution
Predecessor:
International Harvester 275
Successor:
Case IH 285
Production Era:
1974-1983
Production Location
Factory:
Doncaster, UK
🏆 Awards & Recognition
Recognition
Awards:
N/A - no specific awards found
