Allis Chalmers Tractor Model 170 Factory Service Repair Manual

Allis Chalmers Tractor Model 170 Factory Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 99469
Brand
Allis Chalmers
Equipment
Tractors
Models covered
170
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Allis Chalmers
Model:
170
Model Variant:
Base model
Production Years Covered:
1969-1972 (approximate)
👋 Introduction
Market Position
Target Audience:
Farmers, ranchers, and equipment owners who need a reliable utility tractor for fieldwork, loader work, and general farm maintenance.
Competitive Analysis
Advantage:
Allis Chalmers 170 offers high horsepower in a utility chassis, excellent hydraulic capacity, and a comfortable operator station, competing with models like John Deere 4020 and International 806.
Key Features
Key Features:
Powerful 6-cylinder diesel engine, dual-range power shift transmission, power steering, differential lock, hydraulic system with position control, and a robust 3-point hitch.
📋 Manual Details
Coverage
Coverage Areas:
Engine, transmission, hydraulics, electrical, steering, brakes, chassis, and all other systems.
Physical Specification
Page Count:
Approximately 600 pages
Manual Type:
Factory Service Repair Manual
Language:
English
Format:
PDF
Delivery Method:
Instant download
📖 Manual Coverage
Systems Covered
Engine:
Complete engine disassembly, inspection, repair, and reassembly
Transmission:
All transmission components, including power shift units
Hydraulic System:
Hydraulic pump, control valves, cylinders, and 3-point hitch
Electrical System:
Wiring diagrams, starter, alternator, lights, and gauges
Steering:
Manual and power steering systems
Brakes:
Mechanical and hydraulic brakes
Chassis/Sheet Metal:
Body panels, fenders, grille, and mounting points
Procedures Included
Maintenance Procedures:
Scheduled maintenance tasks including lubrication, filter changes, and adjustments
Disassembly/Reassembly:
Step-by-step instructions for component removal and installation
Diagnostic Procedures:
Troubleshooting guides for common issues
Torque Specifications:
Tightening torques for all major fasteners
Technical Depth
Technical Detail Level:
Comprehensive, with detailed diagrams and specifications
Parts Information
Parts Identification:
Exploded views and part numbers for many assemblies
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
All Windows and Mac systems
Requirements:
Adobe PDF Reader and WinZip
Searchability:
Searchable text for quick navigation
Print Quality
Print Quality:
High-resolution pages suitable for printing on standard printers
Binding Type
Binding Type:
Digital (PDF)
Paper Type
Paper Type:
N/A - digital document
⚙️ Engine Specifications
Primary Engine
Engine Type:
Allis Chalmers 6-cylinder diesel
Displacement:
301 cubic inches (4.9 L)
Power Output:
Approximately 90 horsepower
Torque:
N/A - not specified
Fuel System
Fuel Type:
Diesel
Injection Pump:
In-line injection pump
🔧 Transmission
Standard Transmission
Type:
Dual-range power shift
Gears:
16 forward and 8 reverse (approximate)
Features
Clutch:
Hydraulically actuated wet clutch
PTO:
Independent PTO with 540 RPM standard
📐 Dimensions
Exterior Dimensions
Wheelbase:
Approximately 92 inches
Length:
Approximately 144 inches
Weights
Curb Weight:
Approximately 8,500 lbs
🛡️ Safety Features
Safety Overview
Ratings:
N/A - not rated
Active Features
Brakes:
Independent wheel brakes for maneuverability and stopping
Lighting:
Work lights and road lights for visibility
Passive Features
Rollover Protection:
Optional ROPS canopy available
Operator Protection:
Sturdy fenders and floor mat
💡 Technology Features
Infotainment
Audio System:
N/A - not equipped
Driver Assistance
Steering:
Power steering standard
Differential Lock:
Traction assist for slippery conditions
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 100 hours or annually
Transmission Fluid:
Check every 100 hours, change every 500 hours
Hydraulic Fluid:
Check every 100 hours, change every 500 hours
Fluid Specifications
Engine Oil:
SAE 30 or 15W-40 diesel oil (API CC/SE)
Transmission Fluid:
Allis Chalmers hydraulic/transmission fluid or equivalent
Hydraulic Fluid:
Allis Chalmers hydraulic fluid or equivalent
Common Wear Items
Known Issues:
Fuel injection pump seals may leak with age; steering components require regular lubrication
Common Wear Items:
Belts, hoses, filters, brake linings, PTO clutch plates
📚 Vehicle History
Brand Heritage
Manufacturer:
Allis Chalmers, a well-known American tractor manufacturer with roots dating to the early 1900s
Model Evolution
Predecessor:
Model 190 and series
Successor:
Model 175
Production Location
Production Location:
West Allis, Wisconsin, USA
🏆 Awards & Recognition
Recognition
Awards:
N/A - no major awards found
