Allis Chalmers Model D-17 Series IV Tractor Workshop Service Repair Manual

Allis Chalmers Model D-17 Series IV Tractor Workshop Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 75166
Brand
Allis Chalmers
Equipment
Tractors
Models covered
C
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Allis-Chalmers
Model:
D-17 Series IV
Model Variant:
Series IV
Production Years:
1962-1965 (approx.)
👋 Introduction
Market Position
Target Audience:
Farmers and tractor owners seeking a reliable row-crop tractor.
Competitive Advantage:
Known for its rugged construction, power, and hydraulic capabilities.
Key Features
Highlights:
Powerful 4-cylinder engine, multiple hydraulic options, and a comfortable operator station.
📋 Manual Details
Coverage
Areas Covered:
Complete tear-down and rebuild of engine, transmission, hydraulics, electrical, steering, brakes, and more.
Page Count:
Approximately 200+ pages (specific page count not specified).
Format
Manual Type:
Full service repair manual
Language:
English
File Format:
PDF
Delivery Method:
Instant download
📖 Manual Coverage
Systems Covered
General Information:
Model identification, safety notices, and specifications.
Engine:
Disassembly, inspection, cleaning, reassembly, and troubleshooting.
Fuel System:
Carburetor service, fuel pump, and fuel tank.
Cooling System:
Radiator, water pump, and thermostat.
Electrical System:
Wiring diagrams, troubleshooting, and component testing.
Transmission and Drive:
Gear train, shafts, bearings, and clutch.
Hydraulic System:
Pump, lift cover, valves, and cylinder service.
Power Take-Off (PTO):
PTO clutch and driveshaft service.
Steering System:
Gearbox and linkage adjustment.
Front Axle:
Front suspension and trunnion components.
Brakes:
Disc brakes, adjustment, and replacement.
Wheels and Tires:
Tire sizes and wheel bolt torque.
Procedures Included
Tune-up Procedures:
Spark plug replacement, valve adjustment, and ignition timing.
Lubrication Schedule:
Recommended oils and greases for every component.
Service Intervals:
Periodic checks and replacements.
Overhaul Information:
Complete engine and transmission rebuild steps.
Torque Specifications:
Bolt torques for critical fasteners.
Technical Depth
Level:
Detailed, step-by-step instructions suitable for both professional mechanics and experienced DIYers.
Parts Information
Part Numbers:
Reference original part numbers for ordering replacements.
📊 Manual Specifications
File Format
File Type:
PDF (Portable Document Format)
Compatibility:
Works on Windows, Mac, Linux, and most mobile devices with a PDF reader.
Requirements:
Adobe Reader or similar free PDF viewer.
Searchability:
Fully searchable text for quick reference.
Print Specifications
Print Quality:
High-resolution text and graphics for clear printing.
Binding Type:
Digital (no physical binding)
Paper Type:
N/A - digital file
⚙️ Engine Specifications
Engine
Engine Type:
4-cylinder gasoline
Displacement:
230 cubic inches (actual)
Power Output:
Approximately 43 horsepower (drawbar) and 48 PTO (approx.)
Fuel System:
Carburetor, gasoline
Compression Ratio:
6.9:1
🔧 Transmission
Standard Transmission
Type:
Two-range constant-mesh
Speeds:
8 forward and 2 reverse
Optional Transmission
Type:
Power-shift (optional)
Features:
On-the-go shifting for increased productivity.
📐 Dimensions
Exterior Dimensions
Wheelbase:
88 inches (approx.)
Length:
140 inches (approx.)
Weights
Curb Weight:
5,447 pounds (approx.)
🛡️ Safety Features
Ratings
Crash Test Information:
N/A - off-road farm tractor, no crash ratings.
Active Features
Braking System:
Two independent brake pedals for differential braking.
Passive Features
Rollover Protection:
N/A - original models did not have ROPS; aftermarket available.
💡 Technology Features
Infotainment
Audio System:
N/A - no audio system provided.
Driver Assistance
Hydraulic Controls:
Power-adjustable rear wheels and remote hydraulic levers.
🔧 Maintenance
Service Intervals
Engine Oil and Filter:
Every 50 hours or annually (check owner's manual).
Hydraulic Fluid:
Check level daily; change every 500 hours.
Transmission Oil:
Change every 500 hours or annually.
Air Filter:
Clean every 10 hours; replace as needed.
Fluid Specifications
Engine Oil:
API CD/SF, SAE 30 weight (typical) or 15W-40 multi-grade (check manual).
Hydraulic Oil:
Allis-Chalmers hydraulic fluid or equivalent (e.g., universal tractor hydraulic fluid).
Transmission Oil:
SAE 90 gear oil or equivalent.
Known Issues
Common Wear Items:
Ball joints in steering linkage, hydraulic oil leaks, and electrical contacts.
📚 Vehicle History
Heritage
Manufacturer:
Allis-Chalmers Manufacturing Company
Model Evolution
Series IV Introduction:
The D-17 Series IV was a continuation of the popular D-17 line, introduced in 1962.
Production Location
Plant:
West Allis, Wisconsin, USA
🏆 Awards & Recognition
Recognitions
Tractor of the Year:
N/A - no specific awards on record for this model.
