Allis Chalmers Model D-17 Series IV Tractor All Service Repair Manual

Allis Chalmers Model D-17 Series IV Tractor All Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 79420
Brand
Allis Chalmers
Equipment
Tractors
Models covered
C
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Allis Chalmers
Model:
D-17 Series IV
Model Variant:
Series IV
Production Years:
1962-1968 (approx.)
👋 Introduction
Market Position
Target Audience:
Technicians, DIY owners, tractor enthusiasts
Segment:
Utility and row-crop tractor
Competitive Advantage:
Known for durability and fuel efficiency
Key Features
Engine Options:
Gasoline, diesel, LP gas
Transmission:
Shuttle shift, power adjust wheels
Hydraulics:
Power steering and live PTO available
📋 Manual Details
Coverage Areas
Main Components:
Engine, transmission, hydraulics, electrical, chassis
Service Procedures:
Disassembly, inspection, adjustment, reassembly
Format
Page Count:
Approximately 850 pages
Manual Type:
Service and repair manual
Language:
English
Format:
PDF
Delivery:
Instant download
📖 Manual Coverage
Systems Covered
Engine:
In-frame overhaul, fuel system, cooling
Transmission:
Gearbox, clutch, shuttle shift
Hydraulics:
Pump, lift, power steering
Electrical:
Wiring, starter, alternator
Chassis:
Front axle, steering, brakes
Power Take-Off:
Live and independent PTO
Procedures Included
Removal and Installation:
Step-by-step
Overhaul:
Complete engine and transmission rebuild
Adjustments:
Valve clearance, clutch, brakes
Lubrication:
Oil and grease points with specs
Technical Depth
Torque Specs:
Detailed tightening values
Clearances:
Precise measurements for critical parts
Troubleshooting:
Diagnostic charts
Parts Information
Part Numbers:
OEM references
Exploded Views:
Diagrams for assembly
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Windows, Mac, Linux, mobile
Requirements:
PDF reader
Searchability:
Searchable text
Print Quality
Resolution:
High, printable
Binding
Binding Type:
Digital (no physical binding)
Paper Type
Paper Type:
N/A - digital only
⚙️ Engine Specifications
Engine Options
Base Engine:
Allis Chalmers 230 cu in (3.8L) gasoline
Alternative Engines:
Diesel, LP gas versions
Performance
Horsepower:
Approximately 58 hp (PTO)
Torque:
N/A - not specified
Fuel System
Carburetion:
Marvel-Schebler (gasoline)
Injection:
For diesel models
🔧 Transmission
Standard Transmission
Type:
Unsynchronized gear
Speeds:
6 forward, 2 reverse
Optional Transmission
Shuttle:
Shuttle shift available
Speeds:
8 forward, 2 reverse (with shuttle)
Features
Clutch:
Dry disc
PTO:
Live PTO (independent)
📐 Dimensions
Exterior
Wheelbase:
100 inches (approx.)
Length:
150 inches (approx.)
Width:
N/A - varies with tread
Weights
Curb Weight:
Approximately 7,000 lbs (ballasted)
🛡️ Safety Features
Ratings
Crash Test Information:
N/A - tractors not crash tested
Active Features
Rollover Protection:
Optional ROPS
Passive Features
Shields:
PTO shield
Warning Lights:
Indicator lights for oil/amps
💡 Technology Features
Infotainment
Audio System:
N/A - not equipped
Driver Assistance
Power Steering:
Optional
Lighting:
Halogen headlights (if equipped)
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 100 hours
Transmission Fluid:
Change every 500 hours
Hydraulic Oil:
Change every 500 hours
Air Filter:
Clean every 10 hours, replace as needed
Fluid Specifications
Engine Oil:
SAE 30 or 10W-30
Transmission Oil:
ISO VG 46 or equivalent
Hydraulic Oil:
ISO VG 46 or equivalent
Known Issues
Common Wear Items:
Hydraulic seals, clutch disc
Common Issues:
Electrical wiring deterioration
📚 Vehicle History
Brand Heritage
Manufacturer:
Allis Chalmers Manufacturing Company
Heritage:
Founded 1901, known for agricultural equipment
Model Evolution
Series:
Introduced in 1957, Series IV produced 1962-1968
Production Location
Plant:
West Allis, Wisconsin, USA
🏆 Awards & Recognition
Recognition
Awards:
No specific awards found for this model
Legacy:
Considered a classic by vintage tractor enthusiasts
