Allis Chalmers Model D-17 Series III Tractor All Service Repair Manual

Allis Chalmers Model D-17 Series III Tractor All Service Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 79419
Brand
Allis Chalmers
Equipment
Tractors
Models covered
C
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Allis Chalmers
Model:
D-17 Series III
Model Variant:
Series III
Production Years:
1962-1964 (approx.)
👋 Introduction
Market Position and Audience
Target Audience:
Technicians and DIY owners who want to perform repairs and maintenance confidently.
Competitive Advantage:
Comprehensive factory-accurate procedures specific to the D-17 Series III, covering all systems.
Key Features:
Detailed disassembly/assembly instructions, wiring diagrams, hydraulic schematics, and specifications.
📋 Manual Details
Manual Overview
Coverage Areas:
Complete tear-down, repair, and reassembly of the Allis Chalmers D-17 Series III tractor.
Page Count:
Approximately 600 pages (digital).
Manual Type:
Service and repair manual.
Language:
English
File Format:
PDF
Delivery Method:
Instant download after purchase.
📖 Manual Coverage
Systems Covered
Systems Included:
Engine, clutch, transmission, differential, final drives, brakes, steering, hydraulics, electrical, and more.
Procedures Included:
Disassembly, inspection, repair, and assembly steps for every major component.
Technical Depth:
Step-by-step instructions with exploded views and torque specs.
Parts Information:
Part numbers and reference diagrams for commonly replaced items.
Detailed Coverage
Engine Mechanical:
Overhaul procedures for block, head, pistons, valves, and crankshaft.
Cooling System:
Radiator, water pump, thermostat, and cooling system service.
Fuel System:
Carburetor, fuel pump, and governor adjustments.
Ignition System:
Distributor, coil, points, and timing procedures.
Starting and Charging:
Starter motor, generator/alternator, and wiring diagrams.
Clutch:
Clutch adjustment, replacement, and related linkage service.
Transmission (Manual):
Transmission overhaul, gear alignment, and shift linkage.
Differential and Final Drive:
Differential and planetary gear service, axle shaft removal.
Brakes:
Brake adjustment, lining replacement, and hydraulic system.
Steering:
Power steering (if equipped) and manual steering overhaul.
Hydraulic System:
Pump, control valve, cylinder, and draft sensing system.
Three-Point Hitch:
Hitch linkage adjustment and parts.
Power Take-Off (PTO):
PTO assembly and repair.
Electrical System:
Complete wiring diagrams, lights, and switches.
Specifications:
Torque values, clearances, and capacities.
Troubleshooting:
Diagnostic guides for common issues.
Maintenance:
Routine service points.
📊 Manual Specifications
Format and Delivery
File Format:
PDF
Compatibility:
All devices with a PDF reader (PC, Mac, tablet, smartphone).
Requirements:
None
Searchability:
Fully searchable text (electronic PDF).
Print Quality:
High-resolution pages suitable for printing.
Binding Type:
Digital - no physical binding.
Paper Type:
N/A - digital product.
⚙️ Engine Specifications
Engine Options
Engine Type:
Four-cylinder gasoline (standard)
Displacement:
230 ci (approx.)
Power Output:
Approximately 44 hp PTO (max)
Fuel System:
Carbureted, gasoline
Cooling System:
Liquid-cooled
🔧 Transmission
Transmission Options
Standard Transmission:
Manual, 6 forward and 1 reverse (constant mesh)
Optional Transmission:
Power Shift (if equipped) - 6 forward speeds
Features:
Independent PTO, differential lock
📐 Dimensions
Exterior
Wheelbase:
Approximately 84 inches
Length (with 3-point):
Approximately 130 inches
Weights
Curb Weight:
Approximately 5,000 lbs (gasoline)
🛡️ Safety Features
Ratings and Features
Safety Ratings:
N/A - pre-dates formal crash testing
Active Features:
Fenders, headlights
Passive Features:
Seat belt equipped (optional)
💡 Technology Features
Infotainment and Assistance
Infotainment:
N/A - this is a tractor, not a car
Driver Assistance:
N/A - none
🔧 Maintenance
Service Information
Service Intervals:
Engine oil change every 100 hours; transmission and hydraulic fluid change every 500 hours (typical).
Fluid Specifications:
Engine oil: SAE 30 (API CD); hydraulic fluid: Allis Chalmers spec (power fluid 303); coolant: water/glycol mix.
Known Issues:
Wear on clutch throwout bearing, hydraulic pump seals, and electrical wiring insulation.
📚 Vehicle History
Brand and Model History
Brand Heritage:
Allis-Chalmers, a major American agricultural and industrial equipment manufacturer.
Model Evolution:
D-17 Series III was part of the D-17 line; preceded by Series I and II; the Series III featured improvements in engine and hydraulics.
Production Location:
Manufactured in West Allis, Wisconsin, USA.
🏆 Awards & Recognition
Recognition
Awards:
N/A - not specified for this model
