Allis Chalmers D-17 D-17 Series III D-17 Series IV FSM

Allis Chalmers D-17 D-17 Series III D-17 Series IV FSM

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 63685
Brand
Allis Chalmers
Equipment
Tractors
Models covered
C
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Allis Chalmers
Model:
D-17
Model Variants:
D-17 Series III, D-17 Series IV
Production Years:
Series III: 1960-1962; Series IV: 1962-1967 (approximate)
👋 Introduction
Market Position
Target Audience:
Farmers and contractors requiring a versatile row-crop tractor for medium-duty tasks.
Market Segment:
Competitive with Ford 4000, John Deere 3010, and International Harvester 460.
Competitive Advantage
Key Advantage:
Power Director transmission provided eight forward gears for exceptional speed range.
Key Features
Engine:
Available with gasoline, LP gas, or diesel engines, with power up to 63 hp (approx.).
Hydraulics:
Advanced hydraulic system with position control and draft-sensitive linkage for efficient implements.
Operator Comfort:
Deluxe seat and improved visibility over previous models.
📋 Manual Details
Coverage
Applicable Models:
Allis Chalmers D-17, D-17 Series III, and D-17 Series IV
Included Years:
1957-1967 (all D-17 variants)
Physical Attributes
Page Count:
Approximately 600 pages
Manual Type:
Factory Service Manual
Language:
English
Format
File Format:
PDF
Delivery Method:
Instant digital download
📖 Manual Coverage
Service Procedures
Engine:
Complete overhaul procedures, torque specs, and troubleshooting for gasoline, LP, and diesel engines.
Transmission:
Disassembly, repair, and adjustment of Power Director and standard transmissions.
Hydraulic System:
In-depth service of hydraulic pump, valves, lift cylinder, and draft control.
Electrical System:
Wiring diagrams, starter/generator overhaul, and lighting system diagnostics.
Steering:
Adjustments and overhaul for manual and power steering options.
Brakes:
Service and adjustment of mechanical and hydraulic brakes.
PTO:
Repair of independent and live PTO systems.
Cooling System:
Water pump, thermostat, and radiator service.
Fuel System:
Carburetor and injector pump service for different fuels.
Technical Depth
Level of Detail:
Step-by-step instructions with exploded diagrams and illustrations.
Specifications:
Torque specs, clearances, and fluid capacities for all components.
Parts Information:
Exploded views with part numbers for ordering replacement components.
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Works on any device with a PDF reader (Windows, Mac, iOS, Android).
Requirements:
Adobe Acrobat Reader or similar.
Searchability:
OCR text layer allows keyword search within the document.
Physical Print Quality
Print Quality:
High-resolution scan suitable for clear reproduction.
Binding Type:
Digital (no physical binding)
Paper Type:
N/A - digital format
⚙️ Engine Specifications
Engine Options
Gasoline Engine:
Allis-Chalmers 201 CID 4-cylinder, 58 hp (approx.)
LP Gas Engine:
Allis-Chalmers 201 CID 4-cylinder, similar power output.
Diesel Engine:
Allis-Chalmers 201 CID 4-cylinder, 63 hp (approx.)
Performance
Rated Engine Speed:
Around 1800 RPM (exact varies by variant)
Fuel System:
Carburetor on gasoline/LPG, direct injection on diesel.
🔧 Transmission
Standard Transmission
Type:
Manual gear transmission with 4 forward and 1 reverse.
Gear Ratios:
Not specified in this manual.
Optional Transmission
Type:
Power Director (shift-on-the-go) with 8 forward and 2 reverse gears.
Shift Method:
Two-speed power shift in each gear.
📐 Dimensions
Exterior Dimensions
Wheelbase:
83 inches (approx.)
Length:
Approximately 128 inches (without 3-point hitch)
Weights
Curb Weight:
Approximately 5,000 lbs (depending on configuration)
🛡️ Safety Features
Ratings
Crash Test Rating:
N/A - tractors are not crash-tested.
Active Safety
Brakes:
Mechanical or hydraulic independent wheel brakes for tight turns and stopping.
Lighting:
Includes headlights and taillights for road visibility (if equipped).
Passive Safety
ROPS:
Optional roll-over protection structure (retrofit).
Seat Belt:
Optional seat belt for operator safety.
💡 Technology Features
Infotainment
Audio System:
N/A - no factory radio installed.
Driver Assistance
Hydraulic Draft Control:
Automatic hitch response to changes in load.
Power Steering:
Optional power steering reduces operator effort.
🔧 Maintenance
Service Intervals
Oil Change:
Every 120 hours of operation.
Air Filter Cleaning:
Every 10 hours in dusty conditions.
Transmission Fluid:
Check every 10 hours, change annually.
Hydraulic Fluid:
Change every 500 hours.
Fluid Specifications
Engine Oil:
SAE 30 (API service class CC or better).
Transmission/Hydraulic:
Allis-Chalmers Power Fluid 821 or equivalent.
Coolant:
50/50 ethylene glycol mix.
Known Issues
Common Wear Items:
Engine wiring harness degradation, hydraulic seals, PTO seals.
📚 Vehicle History
Brand Heritage
Manufacturer:
Allis-Chalmers Manufacturing Company
Background:
Known for innovation in farm equipment, producing tractors from 1914 to 1985.
Model Evolution
Series III:
Introduced in 1960 with improvements to the hydraulic system.
Series IV:
Launched in 1962 featuring optional power steering and updated sheet metal.
Production Location
Manufacturing Site:
West Allis, Wisconsin, USA
🏆 Awards & Recognition
Model Recognition
Industry Recognition:
The D-17 series was praised for its power and versatility in agricultural publications of its era.
Legacy
Historic Importance:
Now considered a collector's item among vintage tractor enthusiasts.
