Allis Chalmers D-15 D-15 Series II Workshop Service Manual

Allis Chalmers D-15 D-15 Series II Workshop Service Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 63381
Brand
Allis Chalmers
Equipment
Tractors
Models covered
C
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Allis Chalmers
Model:
D-15
Model Variant:
Series II
Production Years Covered:
1961-1969 (Series I and Series II)
👋 Introduction
Market Position
Target Audience:
Farmers and agricultural contractors needing a versatile utility tractor.
Positioning:
Mid-range row-crop tractor with power-shift options.
Competitive Analysis
Advantage:
Traction booster system and power-shift transmission offered enhanced productivity.
Key Features:
Power-shift transmission, Traction Booster, power steering, and diesel or gasoline engine options.
📋 Manual Details
Coverage
Coverage Areas:
Complete tear down and rebuild, including troubleshooting and repair procedures.
Manual Type:
Factory service manual
Page Count:
Approximately 600 pages
Language:
English
Format:
PDF (Portable Document Format)
📖 Manual Coverage
Systems Covered
Engine:
Detailed repair procedures for gasoline and diesel engines.
Cooling System:
Radiator, water pump, thermostat, and cooling system service.
Fuel System:
Carburetor, fuel injection pump, fuel tank, and fuel lines.
Electrical System:
Wiring diagrams, starter, generator/alternator, and lights.
Transmission:
Standard and power-shift transmission disassembly and assembly.
Drive Train:
Clutch, differential, final drives, and PTO.
Steering System:
Manual and power steering gearbox and linkage.
Brake System:
Mechanical and hydraulic brakes.
Hydraulic System:
Hydraulic pump, control valves, cylinders, and lines.
Chassis:
Frame, axles, wheels, and tires.
Sheet Metal:
Hood, grille, fenders, and operator platform.
Operator Station:
Seat, controls, and instrumentation.
Procedures Included
Maintenance:
Scheduled service procedures and adjustments.
Diagnosis:
Step-by-step troubleshooting charts.
Removal & Installation:
Component removal, installation, and replacement.
Disassembly & Assembly:
Complete engine and other major assemblies.
Specifications:
Torque specs, clearances, capacities, and tolerances.
Technical Depth
Level:
In-depth factory service information for professional technicians.
Parts Information:
Exploded views and part numbers for ordering replacement parts.
Illustrations:
Detailed diagrams and photographs.
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Windows, Mac, Linux, iOS, Android
Requirements:
PDF reader software
Searchability:
Bookmarked and searchable
Print
Print Quality:
High resolution – text and graphics are crisp.
Binding Type:
Digital (no physical binding)
Paper Type:
N/A – digital download
⚙️ Engine Specifications
Engine Options
Standard Engine:
Allis Chalmers 149 CID gasoline engine.
Optional Engine:
Allis Chalmers 149 CID diesel engine.
Performance
Power Output:
Approximately 38-40 horsepower (drawbar) depending on configuration.
Rated Speed:
Rated engine speed at 1650 rpm.
Fuel System
Gasoline:
Carburetor with gasoline.
Diesel:
Diesel with fuel injection pump.
🔧 Transmission
Transmission Options
Standard Transmission:
Manual shift, 4-speed forward and 1 reverse.
Optional Transmission:
Power-Shift transmission with 4-speed and 2 ranges giving 8 forward and 2 reverse.
Features:
Power-Shift allows shifting under load without clutching.
📐 Dimensions
Exterior
Wheelbase:
Approximately 82 inches
Length:
Approximately 121 inches (including 3-point hitch)
Weights
Curb Weight:
Approximately 4,600 lb (gasoline, standard transmission)
Shipping Weight:
Approximately 4,700 lb with power-shift.
🛡️ Safety Features
Ratings & Certifications
Crash Test Ratings:
N/A – tractors are not crash tested.
Active Features
Brakes:
Shoe brakes on rear axle with independent left/right pedals.
Throttle Operation:
Hand and foot throttles for control.
Passive Features
Rollover Protection:
Not standard; aftermarket ROPS may be added.
💡 Technology Features
Infotainment
Audio System:
N/A – no factory audio system.
Driver Assistance
Traction Booster:
Hitch system that automatically increases weight transfer under load.
Power Steering:
Optional power steering.
🔧 Maintenance
Service Intervals
Engine Oil:
Change every 100 hours.
Transmission Fluid:
Check every 500 hours; change as needed.
Fluid Specifications
Engine Oil:
SAE 30 API class SD (or modern equivalent).
Transmission/Hydraulic Oil:
Allis Chalmers Type C-1 or equivalent; about 10 gallons for power-shift.
Known Issues & Wear Items
Common Wear Items:
Clutches, brakes, hydraulic hoses.
Common Issues:
Steering box wear, carburetor adjustments.
📚 Vehicle History
Brand Heritage
Manufacturer:
Allis-Chalmers Manufacturing Company
Model Evolution:
D-15 introduced in 1961; Series II in 1964; production until 1969.
Production Location:
West Allis, Wisconsin, USA
🏆 Awards & Recognition
Recognition
Awards:
N/A – specific awards not documented.
