Allis Chalmers D-14 D-15 D-15 Series II Factory Manual

Allis Chalmers D-14 D-15 D-15 Series II Factory Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 63682
Brand
Allis Chalmers
Equipment
Tractors
Models covered
C
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Allis-Chalmers
Model:
D-14, D-15, D-15 Series II
Model Variants:
D-14, D-15, D-15 Series II (includes gasoline and diesel versions)
Production Years:
D-14: 1958-1961; D-15: 1961-1965; D-15 Series II: 1965-1969
👋 Introduction
Market Position
Target Audience:
Farmers, small landowners, and hobby farmers needing a versatile utility tractor for row-crop and light tillage work.
Competitive Advantage:
Allis-Chalmers offered the Power Director transmission providing live PTO and hydraulics, plus a unique roll-shift front axle for adjustable tread width without changing wheel spacings.
Key Features
Engine Options:
Available with Allis-Chalmers 4-cylinder gasoline or diesel engines with high torque backup.
Transmission:
Power Director 8-speed (4 forward with high-low range) with live PTO and hydraulics.
Hydraulics:
Allis-Chalmers Snap-Coupler for quick implement attachment; heavy-duty 3-point hitch.
Operator Comfort:
Two-post folding roll bar available; adjustable seat and easy-reach controls.
📋 Manual Details
Manual Coverage
Coverage Areas:
Complete factory service information for Allis-Chalmers D-14, D-15, and D-15 Series II tractors.
Page Count:
Approximately 600 pages of detailed instructions.
Manual Type:
Factory Service Manual (FSM) with repair, overhaul, and maintenance information.
Language:
English
File Format:
PDF (portable document format)
Delivery Method:
Instant download after purchase
📖 Manual Coverage
Systems Covered
Engine:
Overhaul procedures, troubleshooting, fuel system, cooling, lubrication.
Transmission and Clutch:
Power Director transmission, main gearbox, differential, final drives, clutch adjustment and replacement.
Hydraulic System:
Pump, valves, cylinders, 3-point hitch, Snap-Coupler troubleshooting and repair.
Electrical System:
Wiring diagrams, starter, generator/alternator, lights, gauges.
Steering and Brakes:
Manual and power steering options, mechanical and hydraulic brakes.
Power Take-Off (PTO):
Live PTO operation, PTO shaft and driveline service.
Hitch and Drawbar:
Adjustment and repair of 3-point hitch and drawbar.
Sheet Metal and Cab:
Removal and installation of hood, fenders, and roll bar.
Procedures Included
Disassembly and Assembly:
Step-by-step instructions with torque specs.
Inspection and Measurement:
Clearances, wear limits, and testing procedures.
Troubleshooting:
Diagnostic charts for common issues.
Special Tools:
List of required factory tools and alternatives.
Technical Depth
Detail Level:
Chapters cover complete engine rebuild, transmission overhaul, hydraulic system service, and electrical diagnostics.
Diagrams and Illustrations:
Exploded views and wiring schematics to aid repair.
Specifications:
Includes standard, metric, and decimal equivalents.
Parts Information
Part Numbers:
OEM part numbers for common components.
Parts Manual Reference:
Manual references parts diagrams with part numbers for ordering.
📊 Manual Specifications
File Format
File Type:
PDF
Compatibility:
Works on any device with a PDF reader (Windows, Mac, Linux, iOS, Android).
Requirements:
No special software except a PDF reader.
Searchability:
Text-searchable for quick reference.
Physical Quality
Print Quality:
N/A - digital download, original factory scans are high resolution.
Binding Type:
N/A - digital file (no physical binding)
Paper Type:
N/A - digital file (no physical paper)
⚙️ Engine Specifications
Engine Options
D-14 Engine:
Allis-Chalmers 149 CID 4-cylinder gas, 40 hp (gross); diesel optional (40 hp).
D-15 Engine:
Allis-Chalmers 160 CID 4-cylinder gas, 46 hp (gross); diesel optional (46 hp).
D-15 Series II Engine:
Same as D-15 with improved engine (46 hp gross).
Performance and Fuel System
Fuel System:
Gas: downdraft carburetor with mechanical fuel pump; Diesel: injection pump and direct injection.
PTO Horsepower:
D-14: ~36 hp; D-15: ~42 hp (typical estimates)
Bore and Stroke:
D-14: 3.375 x 4.125 in; D-15: 3.4375 x 4.3125 in
Compression Ratio:
Gas: approximately 7.5:1; Diesel: approximately 16.5:1
🔧 Transmission
Standard Transmission
Type:
Power Director - 8 forward and 2 reverse speeds (4-speed with high-low range)
Live PTO:
Independent of main clutch, engaged with separate lever.
Hydraulic Pump:
Live hydraulics driven by the engine, not the clutch.
Optional Transmission
No Optional:
N/A - only the Power Director was offered for these models.
📐 Dimensions
Exterior
Wheelbase:
74 inches
Length:
Approximately 112 inches (D-15)
Width:
Adjustable front axle, typically 56-80 inches
Height:
75 inches to top of steering wheel
Weights
Curb Weight:
D-14: ~3,500 lbs; D-15: ~3,900 lbs
Shipping Weight:
Similar to curb weight, plus fluids.
🛡️ Safety Features
Ratings and Crash Tests
Safety Ratings:
N/A - tractor safety ratings not applicable (not road vehicles).
Active and Passive Features
Active Features:
Manual and hydraulic brakes, safety start switch, neutral start only.
Passive Features:
Roll bar (optional), seat belt (optional), shielding on engine and PTO.
💡 Technology Features
Infotainment
Audio System:
N/A - tractors of this era had no audio system.
Driver Assistance
Systems:
N/A - mid-20th century tractors had no electronic driver aids.
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 100 hours or annually in normal duty.
Transmission/Hydraulic Oil:
Every 1000 hours or every 2 years.
Air Filter Service:
Clean every 10 hours in dusty conditions; replace as needed.
Fuel Filter Replacement:
Annually or every 500 hours.
Fluid Specifications
Engine Oil:
SAE 30 (API CC/CD) above freezing; SAE 10W-30 in cold weather.
Transmission and Hydraulic Oil:
Allis-Chalmers Power Fluid 821 or equivalent (ISO 46).
Coolant:
50/50 ethylene glycol mixture.
Known Issues and Wear Items
Common Issues:
The D-14 and D-15 may have electrical issues with old wiring; the Snap-Coupler can leak if seals are old.
Wear Items:
Injector nozzles (diesel), water pump, distributor cap/rotor, tie rod ends.
📚 Vehicle History
Brand Heritage
Manufacturer:
Allis-Chalmers Manufacturing Company, a major American farm equipment producer.
Model Evolution
Development:
The D-14 replaced the WD-45; D-15 replaced D-14; D-15 Series II had improved engine and sheet metal.
Successor:
The D-15 Series II was replaced by the D-17 and later models.
Production Location
Factory:
West Allis, Wisconsin, and Gadsden, Alabama (Diecast plant may have produced parts).
🏆 Awards & Recognition
Model Recognition
Historical Significance:
Allis-Chalmers D-series tractors are remembered for their ruggedness and innovative features.
Owner Enthusiast Clubs:
Preserved by Allis-Chalmers collectors and enthusiasts; still used in antique tractor pulls.
Formal Awards:
N/A - no formal awards were recorded for this specific model.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
