73 Vertical Beam and Triangle Antennas by Edward M. Noll

73 Vertical, Beam, and Triangle Antennas by Edward M. Noll (160 pages). This is a fantastic book that covers all aspect of building your own antenna setup. From the Preface: An often-heard comment of the present is: “The days of amateurs building and operating their own equipment are a thing of the past.” To a great extent this is true, since the advent of sophisticated single-sideband equipment has convinced many hams that construction of their own gear is no longer practical. The one big exception to this is in the field of antennas. The amateur, at very little expense and without the requirement of an R&D laboratory, can indulge in experimentation with antennas, sometimes with startling results. 73 Vertical, Beam and Triangle Antennas is the second of a series of books which can make the hobby of amateur radio more than an operational spectator activity. Each antenna described in this book was constructed by the author without assistance. A minimum of tools and equipment were used. You can do the same and use the world as your testing ground. Many of the antennas described in this book compete with, and sometimes surpass, the performance of commercial beams. A number of new approaches in the construction of basic antenna types are detailed. The book is not so much a rehash of common antennas and basic theory as it is a coverage of new approaches and ideas not often used by the amateur. There are 73 individual vertical and beam antennas included in an order that begins with simple construction and progresses in a sequential manner to more complex arrangements. However, if you are interested in only one particular type, you can locate that type immediately and proceed with its erection. 73 Vertical, Beam, and Triangle Antennas is an invitation to some inexpensive education and fun. You will find it very educational and satisfying to put up an antenna that you have calculated, erected, and tuned. You have also gained a conversation peak that can bring you that much nearer to other radio amateurs all over the world. There are very few of them who are not interested in antennas. Contents Preface Section 1: Quarter-Wave Verticals 1 - Half-Wavelength Dipole (Hertz) 2 - Quarter-Wavelength Vertical (Marconi) 3 - Quarter-Wave Vertical, Line-Tuned 4 - Quarter-Wave Vertical with Ground System 5 - 10-15-20 Quarter-Wave Vertical Wand Ground System 6 - Elevated Quarter-Wave Vertical with Wire Ground Plane 7 - Base-Loaded Quarter-Wave Vertical 8 - 20-Meter Quarter-Wave Vertical, Multiband Operation 9 - Elevated 40-Meter Ground Plane 10 - Vertical Radiators and Base Tuner Section 2: 1/2- and 5/8-Wavelength Verticals 11 - Half-Wavelength Verticals 12 - Half-Wave Vertical and Balanced Line 13 - Half-Wave Coaxial Vertical 14 - 5/8-Wavelength Vertical 15 - Three-Quarter Wavelength Vertical Section 3: Phased Verticals 16 - Quarter-Wave End-Fire Pair, 90° 17 - Quarter-Wave End-Fire Verticals, 180° 18 - Quarter-Wave Broadside 19 - Multiband Broadside with Tuner 20 - End-Fire Broadside Combination 21 - Closed-Space End-Fire Vertical 22 - Elevated Two-Element Phased Verticals 23 - Four-Element End-Fire Broadside 24 - 20-Meter End-Fire (180°), Broadside Combination 25 - Eight-Element 10-Meter Vertical 26 - Four-Square Verticals 27 - 10-15-20 Four-Square Vertical Section 4: Low-Band Verticals and Inverted Vees 28 - TV Mast 80-Meter Vertical 29 - Low-Band Vertical with Line or Base Tuner 30 - 80-160 Vertical 31 - 40-80 Vertical 32 - Low-Band Vertical with Gamma- and T-Matching 33 - Short 160-Meter Vertical 34 - Low-Band Inverted Dipoles 35 - Inverted-Vee Antennas 36 - 40-80-160 Inverted Vee Antenna 37 - Three-Quarter Wavelength Titled Inverted Vee Section 5: Two-Element Parasitic Antennas 38 - Parasitic Reflector, Wide spaced 39 - Parasitic Director, Wide Spaced 40 - Two-Element Parasitic Antenna, Closed Spaced 41 - Closed-Spaced Two-Element, Stub Matched 42 - Parasitic Reflector-Director Combination 43 - Inverted-Vee Parasitic 44 - Multiband Inverted-Vee and Parasitic-Element Combinations 45 - Single-Mast Inverted Vee with Parasitic Element 46 - Acute-Angle Vee with Parasitic Element Section 6: Horizontal Phased Arrays 47 - Horizontal End-Fire, 90° and 180° 48 - Broadside and Collinear Two-element Horizontals 49 - Collinear, End-Fire (180°) 50 - End-Fire (90°), Broadside 51 - End-Fire Beam 52 - 10-15 End-Fire Beam, Open-Wire Line 53 - Stacked 10-15 End-Fire Beam Section 7: Yagis, Quads, and Triangles 54 - Three-Element Yagi, Stub-Matched 55 - Three-Element Yagi, Open-Wire Line 56 - Multielement Yagis 57 - Stacked Yagis 58 - Two-Band Inverted-Vee Yagi for Low Bands 59 - 10-15 Three-Element Yagi 60 - Two-Element Quad 61 - Two-Element Quad, Tuned Reflector 62 - Two-Element Quad, Stright Reflector 63 - Two-Element Quad, Director 64 - Three-Element Quad 65 - Two- or Three-Element Quad, TV-Line Feed 66 - Multiband Quad 67 - Low-Band Triangle 68 - Triangle and Parasitic 69 - 160-Meter Two-Element Triangle 70 - 40-80 Three-Element double Triangle 71 - Single-Mast Triangle and Parasitic 72 - 80-Meter Triangle with Ground Radial System 73 - Triangle Turnstile 74 - 15-, 40-, and 80-Meter Triangles 75 - High-Band Triangles Appendix I - Antenna Noise Bridge Appendix II - How to Measure the Velocity Factor of Transmission Line with a Noise Bridge Appendix III - Cutting Half-Wave Sections of Transmission Line Using the Antenna Noise Bridge Appendix IV - Measuring the Rest Frequency and Resistance of an Antenna With the Antenna Noise Bridge Appendix V - Cutting an Antenna to Resce Using an SWR Meter Appendix VI - The Construction and Tuning of a Line Tuner Appendix VII - Antenna Tuner for Long-Wire Vees and Rhombics Appendix VIII - Base Tuner for Vertical Antennas The original book was scanned and converted into this digital file in Adobe Acrobat .pdf format. In order to view this file you will need to have Adobe Acrobat Reader installed on your computer.
