2004 Harley Davidson Road King Flhr Service Repair Workshop Manual

This is the COMPLETE Service and Repair Manual for the 2004 Harley Davidson Road King Flhr Service Repair Workshop Manual. It covers every single detail.

2004 Harley Davidson Road King FLHR Service Repair Workshop Manual PDF VEHICLE/EQUIPMENT INTRODUCTION: The 2004 Harley-Davidson FLHR Road King is a modern classic that captures the essence of American motorcycle touring heritage. The Road King features the iconic solo saddle look with detachable windshield and chrome nacelle giving it a hardtail appearance while providing full modern touring comfort and reliability. It was equipped with the legendary Twin Cam 88 1450cc air-cooled V-twin engine delivering the signature rumble and torque that Harley owners expect. Harley-Davidson Touring platform reached an impressive level of refinement by 2004. The Road King shared its robust frame and suspension architecture with the Electra Glide and Street Glide offering riders the legendary reliability of the twin-downtube frame with isolated engine mounting to reduce vibration at highway cruising speeds. The 5-speed transmission provided relaxed RPM at interstate speeds making cross-country touring comfortable and sustainable. The FLHR has always held a special place in Harley lineup as the motorcycle that looks like the classic panhead-era machines but rides like a thoroughly modern machine. For 2004 it featured Electronic Sequential Port Fuel Injection ESPFI delivering reliable starts smooth throttle response and improved fuel economy over the earlier carbureted models. Combined with the massive aftermarket support and the knowledge of any Harley mechanic this platform has become one of the most beloved motorcycles in history. SERVICE AND REPAIR SCOPE: - Engine Twin Cam 88 removal overhaul and installation - 5-speed transmission disassembly bearing inspection gear measurement - Primary chaincase primary chain drive tension and clutch service - Fuel system ESPFI throttle body injector and sensor diagnostics - Cooling and lubrication oil pump pressure and flow testing - Final drive belt tension sprocket inspection and replacement - Front fork disassembly seal replacement and oil specification - Rear suspension shock inspection and adjustment procedures - Brake system disc rotor runout measurement and pad replacement - Electrical system charging lighting and starter circuit diagnostics - Chassis geometry inspection frame alignment and swingarm bearings - Steering head bearing adjustment and replacement procedures - Accessory windshield installation and wiring TECHNICAL SPECIFICATIONS: - Engine: Twin Cam 88 air-cooled 45-degree V-twin - Displacement: 1450cc 88 cubic inches - Bore x Stroke: 95.3mm x 101.6mm - Compression ratio: 9.0:1 - Fuel system: Electronic Sequential Port Fuel Injection - Transmission: 5-speed constant mesh - Final drive: Reinforced cogged belt - Front suspension: 49mm telescopic fork - Rear suspension: dual coil-over shock absorbers - Front brakes: dual 292mm disc 4-piston calipers - Rear brake: single 292mm disc 4-piston caliper - Wheelbase: 63.5 inches - Seat height: approximately 27.4 inches - Fuel capacity: 5.0 gallons DIAGNOSTIC INFORM

Instant download — no shipping, no waiting. Access it right away and use it as many times as you need.
