Bomag BW141 AD-4 BW151AC-4 BW154AD/AC-4 Service training

Bomag BW141 AD-4,BW151AC-4,154AD/AC-4 service training manual. This is a must if performing maintenance. This manual has all the information that is required to test/ trouble shoot this series of roller. Click the preview button underneath the add to cart button to preview these files. 231 pages. contents: Table of contents Foreword A 1 Documentation A 2 General A 3 Technical data and adjustment values B 1 Maintenance C1 Maintenance schedule C2 DEUTZ diesel engine D 1 Operating side/service side D 2 Starter side D 3 Lubrication oil circuit D 4 Coolant circuit D 5 Fuel system D 6 Checking and adjusting the valve clearance D 11 Plug-type injection pump D 14 Electrical components and measuring points on the engine D 30 Travel drive 141/151-4 E 1 Travel pump E 3 Charge pressure relief valve E 9 High pressure relief valve E 10 Pressure override E 12 Travel motors E 15 Drum reduction gear E 18 Test and adjustment points, travel system E 19 Trouble shooting in travel system E 24 Travel drive 154-4 F 1 Travel motors F 7 Drum reduction gear F 8 Flow divider F 11 Test and adjustment points F 19 Service Training BW 141 - 154 AD/AC-4 Vibration G 1 Vibration pump G 3 High pressure relief valves G 6 Control G 7 Vibration motor G 8 Vibration shut-off valve G 9 Drum BW 141 AD-4 G 11 Drum BW 154 AD-4 G 12 Test and adjustment points, vibration system G 14 Trouble shooting in vibration system G 18 Steering system H 1 Steering pump H 3 Priority valve H 4 Steering valve H 5 Articulated joint H 8 Test and adjustment points H 11 Trouble shooting steering system H 14 Working hydraulics - crab walk J 1 Crab walk valve J 2 Test and adjustment points J 3 Blower drive K 1 Water sprinkler system L 1 AC-variant M 1 Electrics with module description O 1 Wiring diagram Hydraulic diagram Service Training BW 141 - 154 AD/AC-4 - A 1
