Jabiru J230SP 250SP Service Manual PDF Download

Jabiru Aircraft J230SP 250SP Service Manual 267 pages rev A1 may 2011 File Format: PDF Compatible: All Versions of Windows & Mac & Linux Printable: Yes Downloadable: Instant High Speed Download Requirements: Adobe PDF Reader ToC All A1 Updated Table of Contents 16-May-2011 1-7 1-6 A1 Added GRT/Garmin Combo Panel 16-May-2011 1-9 1-9 A1 Corrected air filter part number 16-May-2011 1-15 1-12 A1 Revised approved fuelsethanol prohibited 16-May-2011 2-1 2-1 A1 Added towbar information 16-May-2011 2-7 2-8 A1 Added parking/tiedown information 16-May-2011 2-10.9 2-12 A1 Reversed steps 6 and 7 16-May-2011 2-11.1 2-13 A1 Added window buffing information 16-May-2011 2-11.3 2-14 A1 Clarified paragraph 16-May-2011 3-8.2 3-13 A1 Added horizontal stabilizer replacement 16-May-2011 3-9.2 3-13 A1 Added vertical stabilizer replacement 16-May-2011 5-7.1 5-8 A1 Added brake O-ring fluid compatibility caution 16-May-2011 5-7 5-8 to 5-10 A1 Removed owner authorization for main wheels 16-May-2011 5-11 5-21 to 5-22 A1 Removed owner authorization for nose wheel 16-May-2011 5-11.5 5-22 A1 Removed reference to brake assembly 16-May-2011 6-4 6-7 to 6-9 A1 Added flap position sensor information 16-May-2011 7-19 7-30 A1 Removed owner authorization for head torque; Changed head torque value to 20 ft-lbs 16-May-2011 8-3 8-2 A1 Updated fuel vent line description 16-May-2011 8-8 8-9 to 8-10 A1 Added fuel system schematic diagrams 16-May-2011 9-1 9-1 A1 Removed owner authorization for spinner removal; Added spinner replacement information; Added note on over-tightening spinner screws 16-May-2011 9-8.2 9-9 A1 Removed owner authorization for wood prop torque 16-May-2011 9-8.3 9-10 A1 Removed owner authorization for carbon prop clamp bolt torque 16-May-2011 11-3.3 11-2 A1 Added instructions for recharging dead battery 16-May-2011 11-10.5 11-11 to 11-12 A1 Added instructions for GRT map features update 16-May-2011 11-10.6 11-13 A1 Added text to include Garmin magnetometer 16-May-2011 11-10.8 11-15 A1 Added note on WxWorx radio static 16-May-2011 11-11 11-16 A1 Added note on WxWorx radio static 16-May-2011 8-1 8-1 A1 Updated fuel system description 16-May-2011 8-7 8-6 A1 Added G3X information to fuel gauge description 16-May-2011 JSA SM230SP Revision Summary Section Pages Affected Revision Description Date 11-15.1
