BUELL XB9SX CITY XB12X XB12XT ULYSSES 2008+ BIKE Repair MANU

BUELL XB9SX CITY XB12X XB12XT ULYSSES 2008+ BIKE Repair MANU

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 449505
Brand
Buell
Equipment
Motorcycles
Models covered
Ulysses
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
ENGINE COVERED: 1203 cc 4-STROKE 2-CYL V-TWIN AIR/OIL-COOLED OHV (XB12XT ULYSSES) 984 cc 4-STROKE 2-CYL V-TWIN OHV (XB9SX CITY LIGHTNING) 1203 cc 4-STROKE 2-CYL V-TWIN OHV (XB12X ULYSSES) CONTENTS: GENERAL INFORMATION SPECIFICATION PERIODIC CHECKS TORQUE VALUES ENGINE ROTATION ENGINE REPLACEMENT CAMSHAFT/CYLINDERHEAD CYLINDER & PISTON CLUTCH & ALTERNATOR VALVE TRAIN/CRANKCASE FUEL SYSTEM AIR CLEANER/SENSOR THROTTLE BODY/CONTROL EXHAUST SYSTEM ACTIVE INTAKE FUEL PUMP & TANK COOLING SYSTEM TRANSMISSION PRIMARY DRIVE/SHIFT LINKAGE IGNITION SYSTEM STARTING SYSTEM BRAKE SYSTEM TIRE AND WHEELS FORK AND SHOCK ABSORBER STEERING HEAD BEARINGS SWINGRAM AND BRACE FRAME AND SUBFRAME FAIRING AND HANDLEBAR FOOTPAGES,GUARDS & MOUNTS TROUBLESHOOTING VATTERY CABLES/VOLTAGE BODY ACCESSORIES FUSE AND RELAYS SWITCH & CONNECTORE WIRE HARNESS ELECTRICAL CONNECTORS WIRING DIAGRAM

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
