BT Cargo Range Electric Forklift Truck CBE 4.0 DC CBE 4.5 DC CBE 5.0 DC Workshop Service Repair Manual

Original Illustrated Factory Workshop Service Manual for BT Cargo Range Electric Forklift Truck Type CBE DC. Original factory manuals for BT Forclift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate, maintenance and repair your truck. All Manuals Printable, contains Searchable Text and Navigation Bookmarks Covered models: CBE 4.0 DC CBE 4.5 DC CBE 5.0 DC Format: PDF, 95 Pages Language: English Contents: MECHANICAL SECTION DATA SHEET DRIVERS PLACE Load handling commands DASHBOARD TRUCK LOAD CAPACITY TRACTION UNIT DISASSEMBLE THE REDUCTION UNIT OIL CHANGE BRAKES Service brake system Parking brake system ELECTRIC MOTORS WHEELS/TYRES STEERING GROUP Power steering diagram Filter and power steering oil Steering axle Bearing adjustment LIFTING UNIT Hydraulic control valves Hydraulic system diagram with distributor Lifting unit with electrovalves Hydraulic system diagram with electrovalves Filter and lifting oil MASTS Triplex mast section Mast lubrication and settings MAST LIFTING UNITS Description of the cylinder component parts Checking the chains Checking the forks - Mast tilting setting ELECTRICAL SYSTEM Description of components Accelerator pedal - Battery and battery charger TRUCK LIFTING TABLES Running in maintenance table Maintenance table ELECTRICAL SECTION TECHNICAL FEATURES ELECTRICAL MOTORS FEATURES FUNCTIONAL PERFORMANCES Protection General precautions CONSOLE DESCRIPTION ELECTRONIC CONTROL PANEL LAYOUT CONTACTORS PANEL COMPONENTS PANEL ELECTRICAL CIRCUIT CONNECTION - TRACTION MODULE H3D Configuration of the traction potentiometer SETTING VALVES TRACTION MODULE H3D ALARMS DESCRIPTION - TRACTION MODULE H3D ADJUSTMENTS TABLE TRACTION MODULE H3D ELECTRICAL CIRCUIT CONNECTION - LIFTING MODULE H2P Lifting potentiometer configuration SETTING VALUE - LIFTING MODULE H2P ALARMS DESCRIPTION - LIFTING MODULE H2P ADJUSTMENTS TABLE LIFTING MODULE H2P ELECTRICAL CIRCUIT CONNECTION - LIFTING MODULE HPRC WIRING DIAGRAM INPUT SIGNALS - LIFTING MODULE HPRC (fingertips version) WIRING DIAGRAM INPUT SIGNALS - LIFTING MODULE HPRC (joystick version) WIRING DIAGRAM OUTPUT SIGNALS - FOR ELECTROVALVES FUNCTION DESCRIPTION OF ELECTROVALVES AND HPRC MODULE HPRC module configuration (version with fingertips-joystick) SETTING VALUES - LIFTING MODULE HPRC ALARMS DESCRIPTION - LIFTING MODULE HPRC ADJUSTMENTS TABLE
