Barossa QUARTERBACK 250 Parts Catalog QUA250E

Barossa QUARTERBACK 250ER Parts Catalog SPARE PARTS LIST FOR QUA250E (OIL-COOLED & FRONT DISK BRAKE & REVERSE GEAR) FIG 01 CYLINDER, CYLINDER HEAD FIG 23 SEAT FIG 02 CRANKSHAFT PISTON FIG 24 FRONT WHEEL FIG 03 OIL PUMP FIG 25 FRONT BRAKE FIG 04 CARBURETOR FIG 26 REAR WHEEL FIG 05 VALVE FIG 27 TRANSMISSION STARTER FIG 06 CAM CHAIN TENSIONER FIG 28 REAR BRAKE FIG 07 CRANKCASE FIG 29 STEERING HANDEL CABLE FIG 08 LEFT CRANKCASE COVER FIG 30 HANDLE SWITCH FIG 09 RIGHT CRANKCASE COVER FIG 31 STAND FOOTREST FIG 10 TRANSMISSION STARTER FIG 32 GUARD FIG 11 STARTING MOTOR FIG 33 HEAD LIGHT FIG 12 GEAR SHIFT FIG 34 TAIL LIGHT FIG 13 CLUTCH FIG 35 WIRE HARNESS FIG 14 EXHAUST MUFFLER FIG 36 SPEEDOMETER FIG 15 REAR ARM FIG 37 WARNING FIG 16 REAR SUSPENSION FIG 38 CARRIER REAR FIG 17 FRAME FIG 39 GEAR SPEEDOMETER FIG 18 FRONT SUSPENSION FIG 40 OIL COOLING SET FIG 19 STEERING FIG 41 GEAR CASE FIG 20 FUEL TANK FIG 42 GEAR SHIFT FIG 21 FRONT FENDER FIG 43 REVERSE GEAR LEVER FIG 22 SIDE COVER FIG 44 NUMERICAL INDEX
