Honda

2005-2006 CBR600RR Repair Manual

2005-2006 CBR600RR Repair Manual

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 426682
Brand
Honda
Equipment
Motorcycles
Models covered
CBR Series
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you — re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
🏷️ Basic Information
Identification
Make:
Honda
Model:
CBR600RR
Year:
2005
Model Variant:
CBR600RR (PC37/PC40)
Manual Product Name:
2005-2006 Honda CBR600RR Repair Manual
👋 Introduction
Market Position
Motorcycle Segment:
Supersport, middleweight sportbike
Target Audience:
Performance-oriented riders, track day enthusiasts, experienced DIY mechanics
Competitive Analysis
Key Competitors:
Yamaha YZF-R6, Suzuki GSX-R600, Kawasaki Ninja ZX-6R
Key Features
Vehicle Design Philosophy:
Mass-centralization, aerodynamic efficiency, razor-sharp handling
Manual Value Proposition:
Empowers owners and technicians with factory-level knowledge for maintenance and repair, reducing reliance on expensive dealer services.
📋 Manual Details
Coverage Areas
Engine:
Complete engine overhaul, tuning, and diagnostics
Transmission:
Clutch, gearbox, shift mechanism repair and adjustment
Chassis:
Frame, suspension, steering, wheels, and tires
Electrical System:
Ignition, charging, lighting, starting, ECU, sensors, wiring diagrams
Fuel System:
Fuel injection, injectors, fuel pump, pressure regulator
Brakes:
Hydraulic system, calipers, master cylinders, discs, pads, ABS (if equipped)
Cooling System:
Radiator, fan, thermostat, coolant flow
Exhaust System:
Muffler, catalytic converter, pipework
Bodywork And Fairings:
Disassembly, reassembly, and repair of all body panels
Troubleshooting:
Diagnostic procedures for common and uncommon issues
Maintenance:
Scheduled maintenance, inspections, adjustments
Torque Specifications:
All critical fastener torque values
Wiring Diagrams:
Comprehensive electrical system schematics
Page Count
Total Pages:
Estimated 400-500 pages (typical for a comprehensive repair manual)
Manual Type
Type:
Factory-authorized Repair Manual / Service Manual
Language
Language:
English
Format
Format:
Digital (PDF)
📖 Manual Coverage
Systems Covered
Powertrain:
Engine (CBR600RR, 599cc inline-four), transmission, clutch, fuel injection (PGM-FI)
Chassis And Suspension:
Front telescopic fork (H.M.A.S. type), rear Pro-Link single shock absorber, steering system
Brakes And Wheels:
Front dual hydraulic discs (310mm), rear single hydraulic disc (220mm), wheel specifications, tire pressures
Electrical And Ignition:
Ignition system (DC-CDI), charging system (alternator, regulator/rectifier), lighting, instrumentation, ECU, wiring harness
Fuel And Emission Control:
Fuel pump, injectors, throttle body assembly, exhaust gas recirculation (EGR), evaporative emission control (EVAP)
Cooling And Lubrication:
Radiator, fan, water pump, oil pump, lubrication circuit
Procedures Included
Routine Maintenance:
Oil changes, filter replacements, chain adjustment, spark plug service, air filter cleaning/replacement
Engine Rebuild:
Top-end overhaul (cylinder head, valves), bottom-end overhaul (crankshaft, pistons, connecting rods)
Fuel System Service:
Fuel injector cleaning, fuel pump replacement, fuel pressure testing
Brake System Maintenance:
Brake fluid flush and bleed, pad and disc replacement, master cylinder service
Suspension Adjustment And Repair:
Fork oil change, shock absorber service, linkage lubrication
Electrical Troubleshooting:
Diagnostic steps for common electrical faults, wiring harness repair
Bodywork Disassembly And Reassembly:
Fairing removal and installation, seat removal, tank removal
Diagnostic Fault Codes:
Interpretation and clearing of H.I.S.S. (Honda Ignition Security System) and ECU fault codes
Technical Depth
Depth:
Comprehensive (from basic maintenance to full engine and chassis rebuilds)
Diagnostic Capability:
Advanced, including troubleshooting charts and component testing procedures
Rebuild Instructions:
Detailed step-by-step instructions with exploded diagrams for major component overhauls
📊 Manual Specifications
File Format
Digital Format:
PDF
Searchability:
Fully searchable text content
Printable:
Printable pages for workshop use
Print Quality
Image Resolution:
High-resolution images and diagrams suitable for detailed viewing
Binding Type
Binding:
N/A (Digital Format)
Paper Type
Paper Quality:
N/A (Digital Format)
⚙️ Engine Specifications
Primary Engine
Engine Type:
Inline 4-cylinder, DOHC, 16-valve
Displacement:
599 cc
Bore X Stroke:
67 mm x 42.5 mm
Compression Ratio:
12.0:1
Fuel Delivery:
Programmed Fuel Injection (PGM-FI) with dual injectors per cylinder
Ignition System:
Digital DC-CDI with electronic advance
Cooling System:
Liquid-cooled
Performance
Horsepower:
Approx. 117 hp @ 13,000 rpm (crank)
Torque:
Approx. 6.4 kgf·m (63 Nm) @ 11,000 rpm (crank)
Fuel System
Fuel Tank Capacity:
18 liters (4.7 US gal)
Recommended Fuel:
Unleaded gasoline, 91 octane or higher
🔧 Transmission
Standard
Transmission Type:
6-speed sequential manual
Clutch Type:
Wet, multi-plate
Features
Gear Ratios:
Refer to manual for specific gear ratios (e.g., 1st: 2.750, 2nd: 2.000, 3rd: 1.667, 4th: 1.375, 5th: 1.214, 6th: 1.071)
Final Drive:
O-ring sealed chain, 525 size
📐 Dimensions
Exterior
Length:
2,005 mm
Width:
685 mm
Height:
1,115 mm
Wheelbase:
1,395 mm
Ground Clearance:
130 mm
Seat Height:
820 mm
Weights
Dry Weight:
163 kg (approx.)
Curb Weight:
186 kg (approx., with all fluids)
🛡️ Safety Features
Ratings
Crash Test Ratings:
N/A (Motorcycle, not subjected to automotive crash testing standards)
Active Features
Braking System:
Linked Fuel Injection (LFI) and unified braking system (UBS) were not features of this model. Independent front and rear braking.
Hiss System:
Honda Ignition Security System (HISS) for anti-theft
Passive Features
Lighting:
Multi-reflector halogen headlights, LED taillight
💡 Technology Features
Infotainment
Instrumentation:
Digital LCD multi-function display: speedometer, tachometer, odometer, trip meters, clock, fuel gauge, engine temperature, H.I.S.S. indicator, neutral indicator.
Driver Assistance
ABS Availability:
ABS was an optional feature for certain model years/regions, typically designated by 'ABS' in the model name.
Connectivity
ECU Diagnostics:
Honda's PGM-FI system can be diagnosed using a Honda diagnostic tool or compatible aftermarket scan tool, providing access to real-time data and fault codes.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 6,000 km or 12 months, whichever comes first
Oil Filter Replacement:
Every 12,000 km or 24 months
Air Filter Cleaning:
Every 6,000 km, replacement as needed
Chain Maintenance:
Lubricate every 1,000 km or after riding in wet conditions; adjust tension every 12,000 km or as needed
Spark Plug Replacement:
Every 24,000 km
Coolant Replacement:
Every 24,000 km or 24 months
Fluid Specifications
Engine Oil:
SAE 10W-40 API SG or higher, JASO MA certified
Engine Oil Capacity:
3.0 liters (without filter), 3.2 liters (with filter)
Coolant:
Honda Motorcycle Coolant or equivalent (50/50 mix of ethylene glycol and distilled water)
Brake Fluid:
DOT 4, Honda DOT4 Brake Fluid recommended
Fork Oil:
SHOWA SS-02 (SAE 5W equivalent) or equivalent
Fork Oil Capacity:
466 mL (16.1 US oz)
Known Issues
Common Wear Items:
Chain and sprockets, brake pads, tires, clutch plates (depending on usage)
Potential Electrical Faults:
Regulator/rectifier failure (overheating), intermittent headlight issues (less common)
Engine Specific Concerns:
Some early models might exhibit slightly more wear on valve seats if not maintained diligently. Clutch slave cylinder seal leaks can occur.
📚 Vehicle History
Brand Heritage
Honda Motorsports:
Honda has a long and successful history in motorcycle racing, including MotoGP and World Superbike championships, influencing the design and technology of models like the CBR600RR.
Model Evolution
Cbr600Rr Lineage:
The CBR600RR evolved from the CBR600F and CBR600RR-based CBR600F4i, focusing on track performance and agility. The 2003-2006 generation (PC37/PC40) introduced significant chassis and engine improvements.
Generation Differences 05 06:
The 2005 model received minor styling updates, including different graphics and colors. Mechanically, it remained largely similar to the 2003-2004 model. The 2006 model continued this lineage.
Production
Manufacturing Origin:
Japan
🏆 Awards & Recognition
Recognitions
Industry Acclaim:
Consistently praised by motorcycle publications for its handling, engine performance, and track capability during its production years.
Ratings
Performance Benchmark:
Considered a benchmark for 600cc supersport performance and handling for its generation.

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
